System And Components
399-7524 WIRING GP-AUX START RECEPTACLES/N KNE1-UP
Group No: 399-7524 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 8S2634 | 2 COVER AS | 1 | |
| 3429671 | 3 RECEPTACLE AS-AUXILIARY START | 1 | |
| 4159652 | 4 CABLE AS (BREAKER) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 0301705 | TERMINAL-CABLE (00-GA, 5/16-IN SCREW) | 1 | |
| 1598049 | CABLE (00-GA, RED)(34-CM) | ||
| 4159653 | 5 CABLE AS (DISCONNECT SWITCH) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 2 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(61-CM) | ||
| 4159661 | 6 BRACKET AS | 1 | |
| 3068526 | 7 GROMMET | 1 | |
| 8T1889 | 8 CLIP (SLOT) | 1 | |
| 8T1890 | 9 CLIP (TAB) | 1 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 11 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4191 | 12 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4200 | 13 BOLT (M8X1.25X16-MM) | 1 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 8T4908 | 15 BOLT (M8X1.25X25-MM) | 4 |
