399-7519 WIRING GP-CHASSIS -SMARTBOOMS/N KNE1-UP

Group No: 399-7519 · Commonality

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	7
7I2673	2 STRAP-CABLE	3
7K1181	3 STRAP-CABLE	15
1160118	4 CLIP	1
4356512	5 HARNESS AS-CHASSIS (SMARTBOOM)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	10
3S2093	STRAP-CABLE	1
8T8737	PLUG-SEAL	24
2L8079	TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW)	1
1552270	KIT-CONNECTING PLUG (2-PIN)	2
2304009	PLUG AS-CONNECTOR (12-PIN)	2
4550709	SEAL-CONNECTOR	1
2305010	PLUG AS-CONNECTOR (6-PIN)	1
4550707	SEAL-CONNECTOR	1
4548781	6 HARNESS AS-VALVE	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	2
8T8737	PLUG-SEAL	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM)
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM)
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	6
1261768	SOCKET-CONNECTOR (14-GA TO 16-GA)	6
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	4
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	4
2304011	PLUG AS-CONNECTOR (2-PIN)	1
4550704	SEAL-CONNECTOR	1
2370227	PLUG AS-CONNECTOR (3-PIN)	2
4550705	SEAL-CONNECTOR	1
2434508	RECEPTACLE AS-CONNECTOR (6-PIN)	1
3422972	CAP-CONNECTOR (2-PIN)	1
3422973	CAP-CONNECTOR (3-PIN)	2
1325789	7 CLIP (LADDER)	4
8T4121	8 WASHER-HARD (11X21X2.5-MM THK)	3
8T4191	9 BOLT (M10X1.5X16-MM)	3
