System And Components
457-5319 WIRING GP-CHASSIS -QUICK COUPLER, HIGH PRESSURES/N KNE631-UP
Group No: 457-5319 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 20 | |
| 7K1181 | 2 STRAP-CABLE | 17 | |
| 4576829 | 3 HARNESS AS-CHASSIS (HIGH PRESSURE, COUPLER) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 8T8737 | PLUG-SEAL | 7 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 7 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 7 | |
| 2L8079 | TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW) | 2 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 4550709 | SEAL-CONNECTOR | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2305008 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 4550706 | SEAL-CONNECTOR | 1 | |
| 4775789 | 4 HARNESS AS-VALVE (HIGH PRESSURE, COUPLER) | 1 | |
| 8T4191 | 5 BOLT (M10X1.5X16-MM) | 1 | |
| 2041611 | 6 STRAP-CABLE (DUAL) | 1 | |
| 3474734 | 7 CLIP | 2 | |
| 7I2673 | 8 STRAP-CABLE | 3 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 1 |
