System And Components
342-3296 WIRING GP-VALVES/N KNE1-184
Group No: 342-3296 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G2263 | 1 SPACER (10.5X19X28.5-MM THK) | 3 | |
| 7K1181 | 2 STRAP-CABLE | 7 | |
| 3508192 | 3 HARNESS AS-CONTROL (MAIN CONTROL VALVE) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 8 | |
| 3S2093 | STRAP-CABLE | 4 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 1325789 | 4 CLIP (LADDER) | 5 | |
| 4P7581 | 5 CLIP (LADDER) | 2 | |
| 7X2536 | 6 BOLT (M8X1.25X14-MM) | 1 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4182 | 8 BOLT (M10X1.5X45-MM) | 3 | |
| 8T4191 | 9 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4200 | 10 BOLT (M8X1.25X16-MM) | 1 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 3 |
