System And Components
493-2173 DRIVE GP-SWING -WITHOUT MOTORS/N KNE565-UP
Group No: 493-2173 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7238 | 1 VALVE-SHUTOFF | 1 | |
| 0940611 | 2 WASHER (47.3X76X1-MM THK) | 14 | |
| 1842421 | 3 CONNECTOR AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C6874 | CONNECTOR | 1 | |
| 1912694 | 4 SHAFT-PINION | 1 | |
| 1912696 | 5 CAGE | 1 | |
| 2276221 | 6 BREATHER AS (SWING DRIVE) | 1 | |
| 4H6112 | BREATHER (SWING DRIVE) | 1 | |
| 2276215 | BOSS (1/4-18-THD) | 1 | |
| 2676785 | PIPE | 1 | |
| 4155557 | 7 PIPE AS | 1 | |
| 4155559 | 8 GAUGE-OIL LEVEL | 1 | |
| 4187160 | 9 GEAR-SUN (13-TEETH, 18-TEETH) | 1 | |
| 4187161 | 10 GEAR-SUN (23-TEETH) | 1 | |
| 4187162 | 11 GEAR-PLANETARY (25-TEETH) | 3 | |
| 4187163 | 12 GEAR-PLANETARY (22-TEETH) | 4 | |
| 4187164 | 13 GEAR-RING (69-TEETH) | 1 | |
| 4187167 | 14 SHAFT | 4 | |
| 4187196 | 15 HOUSING | 1 | |
| 4187232 | 16 COVER-HOUSING | 1 | |
| 4187233 | 17 BEARING AS-ROLLER | 8 | |
| 4187234 | 18 CARRIER AS | 1 | |
| 4187235 | 19 CARRIER-PLANETARY | 1 | |
| 4221352 | 20 SPACER (49.6X69.5X6-MM THK) | 2 | |
| 4224054 | 21 RING-RETAINING | 3 | |
| 4512182 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 50 | |
| 4533447 | 23 BOLT (M12X1.75X40-MM) | 20 | |
| 0931730 | 24 RING-RETAINING | 2 | |
| 0950670 | 25 BOLT (M12X1.75X45-MM) | 30 | |
| 5096676 | 26 PIN-SPRING | 4 | |
| 0962653 | 27 RING-RETAINING | 1 | |
| 1359044 | 28 SEAL-LIP TYPE | 2 | |
| 1362904 | 29 BEARING | 1 | |
| 1362940 | 30 BEARING | 1 | |
| 1912697 | 31 SPACER (110X140X90.1-MM THK) | 1 | |
| 2966268 | 32 BEARING AS-ROLLER | 3 | |
| 3K0360 | 33 SEAL-O-RING | 1 | |
| 8J8879 | 34 SEAL-O-RING | 1 | |
| 1U8846 | SEALANT-GASKET |
