Assembly
100%

452-4905 BUCKET GP-DIPPER5598-MM (220-IN) WIDE X 55.8-CU M (73 CU YD) CAPACITY

Group No: 452-4905
Part NumberPart NameQty
44945991 DOOR GP1
45148362 BODY GP1
45170703 SNUBBER GP (GRAPPLE)1
45170714 SNUBBER GP (GRAPPLE)1
45471775 DOWEL8
45471786 WASHER (212.9X304.8X6-MM THK)8
45471797 WASHER (212.9X304.8X3-MM THK)8
45472238 WASHER (238.3X495.3X12-MM THK)4
46679729 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547181PIN AS1
466797310 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547182PIN AS1
