Assembly
100%

452-4955 BUCKET GP-DIPPER5163-MM (203-IN) WIDE X 45.1-CU M (59-CU YD) CAPACITY

Group No: 452-4955
Part NumberPart NameQty
45170701 SNUBBER GP (GRAPPLE)1
45170712 SNUBBER GP (GRAPPLE)1
45249163 DOOR GP1
45249464 BODY GP1
45471775 DOWEL8
45471786 WASHER (212.9X304.8X6-MM THK)8
45471797 WASHER (212.9X304.8X3-MM THK)8
45472238 WASHER (238.3X495.3X12-MM THK)4
46679729 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547181PIN AS1
466797310 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547182PIN AS1
