461-0911 BUCKET GP-DIPPER5162-MM (203-IN) WIDE X 47.4-CU M (62-CU YD) CAPACITY

Group No: 461-0911
Part NumberPart NameQty
45170701 SNUBBER GP (GRAPPLE)1
45170712 SNUBBER GP (GRAPPLE)1
45471773 DOWEL8
45471784 WASHER (212.9X304.8X6-MM THK)8
45471795 WASHER (212.9X304.8X3-MM THK)8
45472236 WASHER (238.3X495.3X12-MM THK)4
46108867 DOOR GP1
46109108 BODY GP1
46679729 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547181PIN AS1
466797310 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547182PIN AS1
