System And Components
462-1504 BUCKET GP-DIPPER5255-MM (207-IN) WIDE X 45.1-CU M (59-CU YD) CAPACITY
Group No: 462-1504
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4494593 | 1 BUMPER | 1 | |
| 4621398 | 2 DOOR GP (WITH LINERS) | 1 | |
| 4621423 | 3 BODY GP (WITH LINERS) | 1 | |
| 4621435 | 4 CAMSHAFT GP | 1 | |
| 4621446 | 5 BUSHING | 1 | |
| 4621447 | 6 BUSHING | 1 | |
| 4621448 | 7 RING-RETAINING | 2 | |
| 4621449 | 8 SEAL | 2 | |
| 4621450 | 9 CAP-END | 1 | |
| 4621451 | 10 PLATE AS (SUPPORT) | 1 | |
| 4621453 | 10A BUSHING | 1 | |
| 4621452 | BLOCK-BEARING | 1 | |
| 4621454 | 11 WASHER | 2 | |
| 4621455 | 12 BLOCK AS | 2 | |
| 4621457 | 12A BUSHING | 1 | |
| 7X0346 | BOLT (5/8-11X2-IN) | 1 | |
| 4621456 | BLOCK | 1 | |
| 4621478 | WASHER (22.2X56.9X15.24-MM THK) | 1 | |
| 4868716 | 13 LINK GP | 1 | |
| 4621485 | 14 PIN GP | 1 | |
| 4621491 | 15 ARM AS (DIPPER) | 1 | |
| 4621492 | ARM AS | 1 | |
| 4621493 | ARM | 1 | |
| 4621494 | HUB | 1 | |
| 4621495 | BAR | 1 | |
| 4621500 | 16 SEAL | 4 | |
| 4667972 | 17 PIN GP | 2 | |
| 6V7688 | LOCKNUT (M20X2.5-THD) | 2 | |
| 7X2568 | BOLT (M20X2.5X180-MM) | 2 | |
| 4524962 | CLAMP | 2 | |
| 4547181 | PIN AS | 1 | |
| 7X0366 | 18 BOLT (3/4-10X2-IN) | 1 | |
| 7X0582 | 19 WASHER-HARD (20X44.5X6-MM THK) | 1 | |
| 7X2488 | 20 BOLT (M20X2.5X160-MM) | 8 | |
| 7X2575 | 21 BOLT (M24X3X60-MM) | 2 | |
| 8T4123 | 22 WASHER (22X35X3.5-MM THK) | 16 | |
| 8T4131 | 23 NUT (M20X2.5-THD) | 8 | |
| 8T4167 | 24 WASHER-HARD (26X44X4-MM THK) | 2 |
