Assembly
100%

467-3537 BUCKET GP-DIPPER6153-MM (242-IN) WIDE X 60.4-CU M (79-CU YD) CAPACITY

Group No: 467-3537
Part NumberPart NameQty
45170701 SNUBBER GP (GRAPPLE)1
45170712 SNUBBER GP (GRAPPLE)1
45471773 DOWEL8
45471784 WASHER (212.9X304.8X6-MM THK)8
45471795 WASHER (212.9X304.8X3-MM THK)8
45472236 WASHER (238.3X495.3X12-MM THK)4
46679467 DOOR GP1
46679728 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547181PIN AS1
46679739 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547182PIN AS1
467353610 BODY GP1
482873111 LUG AS2
451709811A BUSHING1
4517083LUG AS1
