493-1742 BUCKET GP-DIPPER5163-MM (203-IN) WIDE X 42.8-CU M (56-CU YD) CAPACITY

Group No: 493-1742
Part NumberPart NameQty
45170701 SNUBBER GP (GRAPPLE)1
45170712 SNUBBER GP (GRAPPLE)1
45471773 DOWEL8
45471784 WASHER (212.9X304.8X6-MM THK)8
45471795 WASHER (212.9X304.8X3-MM THK)8
45472236 WASHER (238.3X495.3X12-MM THK)4
46679727 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547181PIN AS1
46679738 PIN GP2
6V7688LOCKNUT (M20X2.5-THD)2
7X2568BOLT (M20X2.5X180-MM)2
4524962CLAMP2
4547182PIN AS1
48287319 LUG AS2
45170989A BUSHING1
4517083LUG AS1
493174310 BUCKET GP-DIPPER1
493175711 DOOR GP (DIPPER)1
