System And Components
455-8083 DOOR GPPART OF 455-8103 BUCKET GP-DIPPER
Group No: 455-8083
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1374234 | 1 PLATE-IDENTIFICATION (WORK TOOL) | 1 | |
| 3125694 | 2 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 4494548 | 3 LATCH | 1 | |
| 4494559 | 4 PLATE | 2 | |
| 4494561 | 5 SPACER (LATCH) | 1 | |
| 4494562 | 6 BUMPER | 1 | |
| 4494573 | 7 PLATE-GUIDE | 2 | |
| 4494578 | 8 SHEAVE | 1 | |
| 4494579 | 9 BRACKET AS | 1 | |
| 4494581 | 10 LEVER AS | 1 | |
| 4505262 | 10A BUSHING | 1 | |
| 4494588 | 11 PIN | 1 | |
| 4494589 | 12 BLOCK | 1 | |
| 4494592 | 13 COVER AS | 1 | |
| 4494593 | 14 BUMPER | 1 | |
| 4494594 | 15 SPACER (20.9X26.7X22.2-MM THK) | 4 | |
| 4494595 | 16 PIN | 1 | |
| 4494598 | 17 PIN AS | 1 | |
| 4558082 | 18 DOOR GP (WITH LINERS) | 1 | |
| 4567161 | 19 SHIM (25-MM THK) | 2 | |
| 4567162 | 20 SHIM (12-MM THK) | 1 | |
| 4567163 | 21 SHIM (8-MM THK) | 2 | |
| 2087492 | 22 NUT (M20X2.5-THD) | 2 | |
| 6V7688 | 23 LOCKNUT (M20X2.5-THD) | 4 | |
| 7X2565 | 24 BOLT (M20X2.5X100-MM) | 2 | |
| 7X2571 | 25 BOLT (M20X2.5X240-MM) | 2 | |
| 7Y5253 | 26 BOLT (M36X4X160-MM) | 2 | |
| 8T3018 | 27 LOCKNUT (M36X4-THD) | 2 | |
| 8T4123 | 28 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4192 | 29 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T6381 | 31 BOLT (M20X2.5X120-MM) | 2 |
