System And Components
466-7946 DOOR GPPART OF 467-3537 BUCKET GP-DIPPER
Group No: 466-7946
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4667961 | 1 SPACER (41.3X127X2-MM THK) | 2 | |
| 9X8259 | 2 WASHER (39X66X6-MM THK) | 2 | |
| 3125694 | 3 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 4494561 | 4 SPACER (LATCH) | 1 | |
| 4494562 | 5 BUMPER | 1 | |
| 4494581 | 6 LEVER AS | 1 | |
| 4505262 | 6A BUSHING | 1 | |
| 4494588 | 7 PIN | 1 | |
| 4494589 | 8 BLOCK | 1 | |
| 4494592 | 9 COVER AS | 1 | |
| 4494593 | 10 BUMPER | 1 | |
| 4494594 | 11 SPACER (20.9X26.7X22.2-MM THK) | 4 | |
| 4494595 | 12 PIN | 1 | |
| 4494598 | 13 PIN AS | 1 | |
| 4524917 | 14 LATCH GP | 1 | |
| 4524918 | BAR-LATCH | 1 | |
| 4524919 | INSERT-THREADED | 1 | |
| 3B4516 | LOCKWASHER | 3 | |
| 7X0406 | BOLT (1-8X3-IN) | 3 | |
| 4567161 | 15 SHIM (25-MM THK) | 2 | |
| 4567162 | 16 SHIM (12-MM THK) | 1 | |
| 4567163 | 17 SHIM (8-MM THK) | 1 | |
| 4639657 | 18 BRACKET | 1 | |
| 4639658 | 19 PLATE | 1 | |
| 4639659 | 20 BUMPER | 1 | |
| 4667939 | 21 DOOR GP (WITH LINERS) | 1 | |
| 4810212 | 22 BLOCK AS | 1 | |
| 4810271 | 23 LINK AS | 1 | |
| 4814635 | 24 SOCKET AS | 1 | |
| 5159961 | 25 PLATE-GUIDE | 2 | |
| 5159962 | 26 PLATE-GUIDE | 2 | |
| 1064175 | 27 BOLT (M20X2.5X60-MM) | 2 | |
| 1123926 | 28 BOLT (M20X2.5X110-MM) | 2 | |
| 6V7688 | 29 LOCKNUT (M20X2.5-THD) | 4 | |
| 7X2571 | 30 BOLT (M20X2.5X240-MM) | 2 | |
| 8C8478 | 31 BOLT (M20X2.5X140-MM) | 2 | |
| 8T4123 | 32 WASHER (22X35X3.5-MM THK) | 10 | |
| 8T4131 | 33 NUT (M20X2.5-THD) | 2 | |
| 8T4192 | 34 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4223 | 35 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
