System And Components
482-8684 DOOR GP54-CU YD
Group No: 482-8684
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4828705 | 1 DOOR AS-LINER | 1 | |
| 4494561 | 4 SPACER (LATCH) | 1 | |
| 4494562 | 5 BUMPER | 1 | |
| 4494578 | 6 SHEAVE | 1 | |
| 4494579 | 7 BRACKET AS | 1 | |
| 4494581 | 8 LEVER AS | 1 | |
| 4505262 | 8A BUSHING | 1 | |
| 4494588 | 9 PIN | 1 | |
| 4494589 | 10 BLOCK | 1 | |
| 4494592 | 11 COVER AS | 1 | |
| 4494593 | 12 BUMPER | 1 | |
| 4494594 | 13 SPACER (20.9X26.7X22.2-MM THK) | 4 | |
| 4494595 | 14 PIN | 1 | |
| 4494598 | 15 PIN AS | 1 | |
| 4524917 | 16 LATCH GP | 1 | |
| 3B4516 | LOCKWASHER | 3 | |
| 7X0406 | BOLT (1-8X3-IN) | 3 | |
| 4524918 | BAR-LATCH | 1 | |
| 5510069 | INSERT | 1 | |
| 4567161 | 17 SHIM (25-MM THK) | 2 | |
| 4567162 | 18 SHIM (12-MM THK) | 1 | |
| 4567163 | 19 SHIM (8-MM THK) | 2 | |
| 5159961 | 20 PLATE-GUIDE | 2 | |
| 5159962 | 21 PLATE-GUIDE | 2 | |
| 1123926 | 22 BOLT (M20X2.5X110-MM) | 2 | |
| 6V7688 | 23 LOCKNUT (M20X2.5-THD) | 4 | |
| 7X2571 | 24 BOLT (M20X2.5X240-MM) | 2 | |
| 7Y5253 | 25 BOLT (M36X4X160-MM) | 2 | |
| 8T3018 | 26 LOCKNUT (M36X4-THD) | 2 | |
| 8T4123 | 27 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4131 | 28 NUT (M20X2.5-THD) | 2 | |
| 8T4192 | 29 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T6381 | 31 BOLT (M20X2.5X120-MM) | 2 |
