System And Components
493-1757 DOOR GP4978-MM (196-IN) WIDE X 42.8-CU M (56-CU YD) CAPACITY
Group No: 493-1757
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6381 | 1 BOLT (M20X2.5X120-MM) | 2 | |
| 4494561 | 3 SPACER (LATCH) | 1 | |
| 4494562 | 4 BUMPER | 1 | |
| 4494578 | 5 SHEAVE | 1 | |
| 4494579 | 6 BRACKET AS | 1 | |
| 4494581 | 7 LEVER AS | 1 | |
| 4505262 | 7A BUSHING | 1 | |
| 4494588 | 8 PIN | 1 | |
| 4494589 | 9 BLOCK | 1 | |
| 4494592 | 10 COVER AS | 1 | |
| 4494593 | 11 BUMPER | 1 | |
| 4494594 | 12 SPACER (20.9X26.7X22.2-MM THK) | 4 | |
| 4494595 | 13 PIN | 1 | |
| 4494598 | 14 PIN AS | 1 | |
| 4524917 | 15 LATCH GP | 1 | |
| 3B4516 | LOCKWASHER | 3 | |
| 7X0406 | BOLT (1-8X3-IN) | 3 | |
| 4524918 | BAR-LATCH | 1 | |
| 5510069 | INSERT (LATCH) | 1 | |
| 4567161 | 16 SHIM (25-MM THK) | 2 | |
| 4567162 | 17 SHIM (12-MM THK) | 1 | |
| 4567163 | 18 SHIM (8-MM THK) | 2 | |
| 4931758 | 19 DOOR AS-LINER | 1 | |
| 5159961 | 20 PLATE-GUIDE | 2 | |
| 5159962 | 21 PLATE-GUIDE | 2 | |
| 2087492 | 22 NUT (M20X2.5-THD) | 2 | |
| 6V7688 | 23 LOCKNUT (M20X2.5-THD) | 4 | |
| 7X2565 | 24 BOLT (M20X2.5X100-MM) | 2 | |
| 7X2571 | 25 BOLT (M20X2.5X240-MM) | 2 | |
| 7Y5253 | 26 BOLT (M36X4X160-MM) | 2 | |
| 8T3018 | 27 LOCKNUT (M36X4-THD) | 2 | |
| 8T4123 | 28 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4192 | 29 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
