System And Components
509-9163 BUCKET GP-DITCH CLEANING1800-MM (72-IN) WIDE X 0.6-CU M (0.78-CU YD) CAPACITY
Group No: 509-9163
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8257 | 1 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1469351 | 3 SHIM (1-MM THK) | 4 | |
| 1598035 | 4 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 5 FILM-WARNING (READ OMM) | 1 | |
| 4339730 | 6 FILM-WARNING (EXPLOSION, WIRELESS, OMM, INTL) | 1 | |
| 4988996 | 7 PIN AS | 2 | |
| 4988997 | 8 PIN GP-BUCKET | 1 | |
| 4828870 | 9 PLATE | 1 | |
| 4842102 | 10 CYLINDER GP-BUCKET (LH) | 1 | |
| 4848127 | 11 SPACER (35X90X3-MM THK) | 1 | |
| 5093245 | 12 LINES GP-BUCKET TILT CYLINDER (312-LINKAGE) | 1 | |
| 4842103 | 13 CYLINDER GP-BUCKET (RH) | 1 | |
| 5099170 | 14 PIVOT AS | 1 | |
| 4845091 | 14A BUSHING | 2 | |
| 9R2672 | 14B BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 1788507 | 14C PLATE-WELD | 2 | |
| 5585895 | 14D PLATE | 1 | |
| 5680343 | 15 CONTROL GP-ELECTRONIC (WORK TOOL) | 1 | |
| 5784709 | 17 PIN AS | 1 | |
| 7V2804 | 18 WASHER-HARD (28X95X8-MM THK) | 1 | |
| 7X2572 | 19 BOLT (M24X3X35-MM) | 1 | |
| 7X2621 | 20 BOLT (M10X1.5X12-MM) | 2 | |
| 8T4222 | 21 WASHER-PLATED (11X32X2.5-MM THK) | 2 | |
| 8T4779 | 22 BOLT (M16X2X35-MM) | 2 | |
| 5099153 | 23 BUCKET AS-DITCH CLEANING | 1 | |
| 4677765 | 24 EDGE-BASE | 1 | |
| 5099725 | 25 PLATE AS-HINGE | 1 | |
| 4848134 | 25A BOSS | 2 | |
| 4851388 | 25B BOSS | 2 | |
| 5099204 | 25C PLATE-GUARD | 2 | |
| 4421826 | 26 PLATE-WEAR | 2 | |
| 4857928 | 27 PLATE-WEAR | 1 | |
| 2C9259 | 28 PLATE-IDENTIFICATION (CAT) | 1 | |
| 4421795 | 29 PLATE (CORNER) | 2 | |
| 5099193 | 30 PLATE | 2 | |
| 5099196 | 31 PLATE-SIDE | 2 | |
| 9R2672 | 32 BOSS-THREADED (M10X1.5X20-MM) | 2 | |
| 9R2821 | 33 BOSS (M10X1.5X15-MM) | 2 | |
| 4827577 | 34 GUSSET (LH) | 1 | |
| 4827578 | 35 GUSSET (RH) | 1 | |
| 5099277 | 36 BAR | 1 |
