System And Components
510-6698 BUCKET GP-DITCH CLEANING1800-MM (72-IN) WIDE X 0.78- CU M (1.02-CU YD) CAPACITY
Group No: 510-6698
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4959816 | 1 COVER-CYLINDER (LH) | 1 | |
| 8T4222 | 2 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 5106733 | 3 PIVOT AS | 1 | |
| 9R2672 | 3A BOSS-THREADED (M10X1.5X20-MM) | 3 | |
| 9R2821 | 3B BOSS (M10X1.5X15-MM) | 1 | |
| 1788507 | 3C PLATE-WELD | 2 | |
| 4829099 | 3D BUSHING | 2 | |
| 3B8489 | 4 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1598035 | 5 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 6 FILM-WARNING (READ OMM) | 1 | |
| 4638184 | 7 COVER-CYLINDER (RH) | 1 | |
| 4663099 | 8 SPACER (35X90X6-MM THK) | 1 | |
| 4699342 | 9 CYLINDER GP-BUCKET (LH) | 1 | |
| 4699353 | 10 CYLINDER GP-BUCKET (RH) | 1 | |
| 8T4779 | 11 BOLT (M16X2X35-MM) | 2 | |
| 9X8257 | 12 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 4982871 | 13 PIN AS | 1 | |
| 4982872 | 14 PIN AS | 2 | |
| 4982873 | 15 PIN AS | 1 | |
| 5094753 | 16 LINES GP-BUCKET TILT CYLINDER | 1 | |
| 7X2621 | 17 BOLT (M10X1.5X12-MM) | 3 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 4 | |
| 5106705 | 20 BUCKET AS-DITCH CLEANING | 1 | |
| 9R2672 | 21 BOSS-THREADED (M10X1.5X20-MM) | 4 | |
| 9R2821 | 22 BOSS (M10X1.5X15-MM) | 2 | |
| 4421826 | 23 PLATE-WEAR | 1 | |
| 4428279 | 24 EDGE | 1 | |
| 4494612 | 25 PLATE-WEAR | 1 | |
| 4827577 | 26 GUSSET (LH) | 1 | |
| 4827578 | 27 GUSSET (RH) | 1 | |
| 5099277 | 28 BAR | 1 | |
| 4428290 | 29 PLATE (CORNER) | 2 | |
| 5106715 | 30 PLATE | 2 | |
| 5106718 | 31 PLATE-SIDE | 2 | |
| 2C9259 | 32 PLATE-IDENTIFICATION (CAT) | 1 |
