System And Components
525-9301 BUCKET GP-DITCH CLEANING -B-FAMILY2200-MM (86-IN) WIDE X 1.35-CU M (1.77-CU YD) CAPACITY
Group No: 525-9301
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4222 | 1 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1598035 | 3 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 4 FILM-WARNING (READ OMM) | 1 | |
| 4663099 | 5 SPACER (35X90X6-MM THK) | 1 | |
| 4699342 | 6 CYLINDER GP-BUCKET (LH) | 1 | |
| 4699353 | 7 CYLINDER GP-BUCKET (RH) | 1 | |
| 4755000 | 8 PIN AS | 2 | |
| 4755002 | 9 PIN AS | 1 | |
| 4755004 | 10 PIN AS | 1 | |
| 8T4779 | 11 BOLT (M16X2X35-MM) | 2 | |
| 9X8257 | 12 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 5093246 | 13 LINES GP-BUCKET TILT CYLINDER | 1 | |
| 5115353 | 14 PIVOT AS | 1 | |
| 4829099 | 14A BUSHING | 2 | |
| 9R2672 | 14B BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 9R2821 | 14C BOSS (M10X1.5X15-MM) | 1 | |
| 1788507 | 14D PLATE-WELD | 2 | |
| 7X2621 | 15 BOLT (M10X1.5X12-MM) | 3 | |
| 5259302 | 16 BUCKET AS-DITCH CLEANING | 1 | |
| 9R2672 | 17 BOSS-THREADED (M10X1.5X20-MM) | 4 | |
| 9R2821 | 18 BOSS (M10X1.5X15-MM) | 2 | |
| 4416614 | 19 EDGE | 1 | |
| 4827577 | 20 GUSSET (LH) | 1 | |
| 4827578 | 21 GUSSET (RH) | 1 | |
| 2C9259 | 22 PLATE-IDENTIFICATION (CAT) | 1 | |
| 4416131 | 23 PLATE (CORNER) | 1 | |
| 5115358 | 24 PLATE | 1 | |
| 5115360 | 25 PLATE-SIDE | 1 |
