System And Components
452-3474 CYLINDER & LINES GP-BOOM110-MM (4.3-IN) BORE X 998-MM (39.3-IN) STROKE
Group No: 452-3474
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3924571 | 1 ROD AS | 1 | |
| 4308077 | 2 HEAD | 1 | |
| 3924573 | 3 CYLINDER AS-BOOM | 1 | |
| 3924574 | 4 PISTON | 1 | |
| 4774239 | 5 KIT-TUBE | 1 | |
| 3924576 | 6 KIT-SEAL (BOOM CYLINDER) | 1 | |
| 3924577 | 7 KIT-PISTON SEAL | 1 | |
| 3924578 | 8 KIT-PISTON | 1 | |
| 3924579 | 9 KIT-BUSHING | 1 | |
| 4185336 | 10 NUT (M56X2-THD) | 1 | |
| 4522752 | 11 FITTING-GREASE | 2 | |
| 8T4191 | 12 BOLT (M10X1.5X16-MM) | 2 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 4185345 | 14 SPACER | 1 | |
| 4185346 | 15 SLEEVE | 1 | |
| 4774240 | 16 KIT-FITTING | 1 | |
| 5000871 | 17 KIT-BRACKET | 1 | |
| 8T1160 | 18 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 2 | |
| 4171060 | 19 VALVE GP-CHECK & RELIEF | 1 |
