System And Components
452-3475 CYLINDER & LINES GP-STICK -STICK LOWERING CONTROL VALVE90-MM (3.54-IN) BORE X 932-MM (36.7-IN ) STROKE
Group No: 452-3475
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3924580 | 1 ROD AS | 1 | |
| 3924581 | 2 HEAD | 1 | |
| 3924582 | 3 CYLINDER AS-STICK | 1 | |
| 3924583 | 4 PISTON | 1 | |
| 2550696 | 5 BOLT-SOCKET HEAD (M6X1X14-MM) | 2 | |
| 4171061 | 6 VALVE GP-CHECK & RELIEF | 1 | |
| 8T1160 | 7 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 2 | |
| 4522752 | 8 FITTING-GREASE | 1 | |
| 3924588 | 9 KIT-BUSHING | 1 | |
| 0951267 | 10 SETSCREW-SOCKET (M10X1.5-THD) | 1 | |
| 6V3938 | 11 BOLT (M10X1.5X20-MM) | 1 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5000872 | KIT-TUBE | 1 | |
| 3924585 | KIT-SEAL (STICK CYLINDER) | 1 | |
| 3924586 | KIT-PISTON SEAL | 1 | |
| 3924587 | KIT-PISTON | 1 | |
| 5000873 | KIT-FITTING | 1 | |
| 5000874 | KIT-BRACKET | 1 |
