System And Components
419-9594 FRAME GP-WINDOW -CABPART OF 419-9575 WINDOW GP-FRONT
Group No: 419-9594
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1613698 | 1 SEAL | 1 | |
| 1717420 | 2 CLIP | 3 | |
| 2743530 | 3 GLASS (WIPER AREA) | 1 | |
| 2743538 | 4 ARM-WINDOW WIPER | 1 | |
| 2743539 | 5 BLADE AS-WIPER (500-MM) | 1 | |
| 2743541 | 6 CAP | 2 | |
| 2743552 | 7 COVER | 1 | |
| 4191293 | 8 MOTOR AS-WINDOW WIPER | 1 | |
| 4191288 | 9 FRAME AS | 1 | |
| 4199614 | 10 BRACKET AS | 1 | |
| 4199615 | 11 BRACKET AS | 1 | |
| 4199617 | 12 ROLLER | 2 | |
| 4191289 | 13 GLASS (MAIN) | 1 | |
| 2743526 | 14 STOP-RUBBER | 2 | |
| 6V8231 | 15 NUT (M10X1.25-THD) | 2 | |
| 9X2045 | 16 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 4199619 | 17 SEAL (219-CM) | ||
| 6V8225 | 18 NUT (M6X1-THD) | 1 |
