481-4243 HOOD GP-ENGINES/N YKY2537-UP

Group No: 481-4243
Part NumberPart NameQty
48803861 INSULATION1
6S71002 LAMP AS (12-VOLT)1
6S7101LENS (WHITE)1
6S7117LAMP (12-VOLT)1
6V46043 RIVET-POP4
28577024 COVER-LATCH1
36936975 LATCH AS1
1910348GROMMET1
57663666 FRAME AS1
8T3490NUT-WELD (M10X1.5-THD)4
7T1099LINK2
3980788HINGE AS2
42158727 HOOD-ENGINE1
42299828 INSULATION2
42299839 INSULATION1
422998410 INSULATION1
423305111 PLATE AS1
6V9632NUT-WELD (M6X1-THD)2
7T1099LINK1
423305412 PLATE1
423305513 PLATE1
438345014 BUMPER2
439167015 INSULATION2
488038716 INSULATION1
488038817 INSULATION1
488038918 INSULATION1
488039019 INSULATION1
488039120 INSULATION1
488039221 INSULATION1
488039322 INSULATION1
489410523 INSULATION1
5P411624 WASHER-HARD (8.8X20.5X2-MM THK)6
8T417125 BOLT (M6X1X12-MM)2
8T418926 BOLT (M8X1.25X20-MM)6
9M587027 GROMMET1
054791328 SEAL (5-DM)
262793529 SEAL (76.5-CM EACH)
146041430 SEAL (57-CM)
123382731 SEAL (66-CM EACH)
