System And Components
515-6099 CAB GP-ENCLOSED ROPSPART OF 461-3041, 485-0665 CAB AR-ENCLOSED ROPS
Group No: 515-6099
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X2536 | 1 BOLT (M8X1.25X14-MM) | 4 | |
| 1R5998 | 2 LOCKWASHER | 4 | |
| 4I3090 | 3 SEAL | 3 | |
| 6V9674 | 4 SCREW-MACHINE (M5X0.8X14-MM) | 2 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 6 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4224 | 7 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1274003 | 8 GROMMET | 4 | |
| 1892864 | 9 SCREW-FLAT HEAD (M8X1.25X30-MM) | 4 | |
| 2612426 | 10 LAMP GP-DOME (12-VOLT, 5-WATT)(CAB) | 1 | |
| 4200070 | 11 GLASS (REAR, LH) | 1 | |
| 4217027 | 12 GLASS (REAR, RH) | 1 | |
| 4375049 | 13 CAP | 4 | |
| 4375063 | 14 STRIKER AS-LATCH | 2 | |
| 4405543 | 15 TRIM | 1 | |
| 4410021 | 16 SEAL | 1 | |
| 4410058 | 17 HANDRAIL | 1 | |
| 4624688 | 18 CAB AS | 1 | |
| 4675558 | 19 GLASS-FRONT | 1 | |
| 4675572 | 20 SWITCH AS (CAB LIGHT) | 2 | |
| 4676695 | 21 BRACKET | 1 | |
| 4676707 | 22 BRACKET | 1 | |
| 4676708 | 23 BRACKET | 1 | |
| 4709658 | 24 SEAL | 1 | |
| 4918353 | 25 TRIM | 2 | |
| 5156097 | 26 GLASS (REAR) | 1 | |
| 5673659 | 27 SCREW-MACHINE (M5X0.8-THD) | 2 | |
| 5673700 | 28 GLASS (FRONT, RH) | 1 | |
| 5673701 | 29 GLASS (FRONT, LH) | 1 |
