System And Components
469-9569 DOOR GP-CAB -WITH SLIDING WINDOW, LHPART OF 461-3038, 461-3041, 485-0665 CAB AR-ENCLOSED ROPS
Group No: 469-9569
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2521862 | 1 HANDLE AS-PULL | 1 | |
| 2521863 | 2 GASKET | 1 | |
| 2924754 | 3 KNOB | 1 | |
| 3370176 | 4 LOCK-DOOR (LH) | 1 | |
| 4244732 | 5 COVER | 1 | |
| 4336359 | 6 WINDOW AS | 1 | |
| 4336878 | 7 FASTENER | 3 | |
| 4368670 | 8 PLATE AS | 1 | |
| 4409525 | 9 SEAL-WASHER | 2 | |
| 4409529 | 10 BAR | 1 | |
| 4409531 | 11 BLOCK | 1 | |
| 4412537 | 12 SEAL-DOOR | 1 | |
| 4412555 | 13 SEAL | 1 | |
| 4412556 | 14 SEAL | 1 | |
| 4412557 | 15 STRIKER | 1 | |
| 4412558 | 16 GLASS | 1 | |
| 4832899 | 17 DOOR AS (LH) | 1 | |
| 4864064 | 18 HANDRAIL | 1 | |
| 0965486 | 19 SCREW-MACHINE (M6X1X25-MM) | 3 | |
| 0996418 | 20 NUT (M6X1-THD) | 1 | |
| 1272170 | 21 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 6 | |
| 7X7729 | 22 WASHER (11X25X3-MM THK) | 2 | |
| 8T4133 | 23 NUT (M10X1.5-THD) | 2 | |
| 9X2040 | 24 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 2 | |
| 9X2045 | 25 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 |
