System And Components
464-3223 FENDER GP-FRONT -2-WHEEL DRIVES/N LBS1-UP
Group No: 464-3223
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1990783 | 1 BOLT (M16X2X38-MM) | 4 | |
| 3751372 | 2 BRACKET AS (LH) | 1 | |
| 3751373 | 3 BRACKET AS (RH) | 1 | |
| 3775319 | 4 PLATE | 2 | |
| 4643253 | 5 FENDER (RH) | 1 | |
| 4643254 | 6 FENDER (LH) | 1 | |
| 6V7744 | 7 LOCKNUT (M10X1.5-THD) | 4 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4122 | 9 WASHER-HARD (17X32X3.5-MM THK) | 12 | |
| 8T4137 | 10 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4195 | 11 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4222 | 12 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 8T4778 | 13 LOCKNUT (M16X2-THD) | 4 |
