System And Components
397-1565 LINES GP-SWING CYLINDERS/N LBS1-UP
Group No: 397-1565
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2042281 | 1 STRAP-CABLE | 3 | |
| 2063685 | 2 VALVE GP-CUSHION CROSSOVER RLF (SWING CONTROL) | 1 | |
| 7I8084 | PLUG | 2 | |
| 2265634 | 3 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1670566 | CARTRIDGE | 1 | |
| 2265633 | CONNECTOR | 1 | |
| 3628279 | 4 HOSE AS | 2 | |
| 3628281 | 5 HOSE AS | 1 | |
| 3628282 | 6 HOSE AS | 1 | |
| 3689866 | 7 HOSE AS | 1 | |
| 4311808 | 8 HOSE AS | 1 | |
| 1488340 | 9 CONNECTOR AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488351 | 10 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1488364 | 11 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488428 | 12 TEE AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8782 | TEE | 1 | |
| 1557321 | 13 ADAPTER AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V1722 | ADAPTER | 1 | |
| 5C7261 | 14 NUT (M8X1.25-THD) | 2 | |
| 8M2773 | 15 CLIP (LOOP) | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6870 | 19 BOLT (M8X1.25X70-MM) | 2 |
