System And Components
112-3465 BURNER GP -DIESEL HEATS/N 2LN1-3598; 2MN1-3541
Group No: 112-3465
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8I0157 | 1 CHAMBER AS-UPPER BURNER | 4 | |
| 8T4835 | 2 BOLT (1/2-13X2-IN) | 16 | |
| 8T4223 | 3 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8I0156 | 4 CHAMBER AS-LOWER BURNER | 4 | |
| 8T8013 | 5 GLOW PLUG (12-VOLT)(M18X1.5THD)(108.9MM LG) | 4 | |
| 8T8917 | 6 BOLT (1/2-13X1.25-IN) | 16 | |
| 8J1256 | 7 CLIP (LOOP) | 8 | |
| 8I0997 | 8 CONNECTOR AS | 4 | |
| 8I0998 | 9 BRACKET-MOUNTING | 4 | |
| 5P2566 | 10 BOLT (1/2-13X1.5-IN) | 8 | |
| 6V8188 | 11 NUT (1/2-13-THD) | 8 | |
| 8M6802 | 12 SCREW-HEX SOCKET (1/4-20X1-IN) | 16 | |
| 8T4205 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 6V8185 | 14 NUT (1/4-20-THD) | 16 | |
| 1090334 | 15 MOTOR GP-BURNER BLOWER (24-VOLT)(24 V) | 4 | |
| 1022697 | 16 WHEEL-BLOWER | 4 | |
| 1022698 | 17 HOUSING-BLOWER | 4 | |
| 0454065 | 18 SCREW-MACHINE (10-32X0.75-IN) | 16 | |
| 9F8125 | 19 LOCKWASHER | 16 | |
| 1022736 | 20 SCREEN-INLET | 4 | |
| 0309612 | 21 SCREW-FORMING (10-24X0.5-IN) | 16 | |
| 4B4274 | 22 WASHER (5.5X13X1.2-MM THK) | 8 | |
| 1022706 | 23 RING-FLAME | 4 | |
| 1022688 | 24 NOZZLE | 4 | |
| 1022725 | 25 ADAPTER | 4 | |
| 1118140 | 26 VALVE-CHECK | 4 | |
| 8I0163 | 27 INSULATION | 4 | |
| 5P1076 | 28 WASHER-HARD (13.5X30X4-MM THK) | 16 | |
| 1041797 | 29 TUBE | 4 |
