System And Components
116-3294 PLATE & FILM GPS/N 4XN1-UP
Group No: 116-3294
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1164199 | 1 FILM | 2 | |
| 0819652 | 2 FILM-WARNING (HOPPER SUPPORT) | 2 | |
| 0817227 | 3 FILM-WARNING (MACHINE MOUNTING) | 2 | |
| 1169884 | 4 FILM-NOTICE (MACHINE SHIPPING) | 2 | |
| 0816767 | 5 FILM-WARNING (NO STEP) | 2 | |
| 1166175 | 6 FILM-IDENTIFICATION (BARBER-GREENE) | 2 | |
| 4P6422 | 7 FILM-WARNING (NO ETHER SPRAY/AIR INTAKE) | 1 | |
| 6V4611 | 8 FILM-WARNING (JUMP START, READ OMM) | 1 | |
| 1166173 | 9 FILM-STRIPE | ||
| 1162196 | 10 PLATE-WARNING (OPERATING INSTRUCTIONS) | 1 | |
| 1296813 | 11 FILM (TOW POINT CYLINDER) | 1 | |
| 1297680 | 12 FILM-INSTRUCTION (HYDRAULIC TANK OIL DRAIN) | 1 | |
| 4B4161 | 13 SCREW-DRIVE (NO 6X3/8-IN) | 4 | |
| 3S2093 | 14 STRAP-CABLE | 1 | |
| 5P9466 | 15 PLATE-WARNING (READ OMM) | 1 | |
| 1072760 | 16 TAG | 1 | |
| 0816617 | 17 FILM-INSTRUCTION (MANUALS INSIDE) | 1 | |
| 5P9796 | 18 COMPARTMENT AS | 1 | |
| 5S7349 | 19 BOLT (1/4-20X0.5-IN) | 4 | |
| 8T4205 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8C4316 | 21 FILM-IDENTIFICATION (HYDRAULIC OIL) | 1 | |
| 5P7957 | 22 LANYARD | 1 | |
| 7X7644 | 23 FILM-IDENTIFICATION (TIE-DOWN) | 1 | |
| 1358013 | 24 TAG-ANTIFREEZE (EXTENDED LIFE COOLANT) | 1 | |
| 1347258 | 25 FILM-INFORMATION (EXTENDED LIFE COOLANT) | 1 | |
| 5P7958 | 26 SLEEVE-CABLE SPLICE | 1 | |
| 5P8502 | PADLOCK GP | 9 | |
| 6V5874 | COVER | 1 | |
| 5P8500 | KEY | 1 | |
| 9N7042 | CHAIN AS (HOPPER) | 1 | |
| 4P6422 | 27 FILM-WARNING (NO ETHER SPRAY/AIR INTAKE) | 1 | |
| 7X3229 | 28 FILM-IDENTIFICATION (LIFT EYE, TIE-DOWN LOCATION)(OR TIE DOWN) | 4 | |
| 1158044 | 29 FILM-NOTICE (SHIPPING) | 1 | |
| 6V9745 | 30 PLATE | 1 | |
| 4B4161 | 31 SCREW-DRIVE (NO 6X3/8-IN) | 12 | |
| 8C4535 | 32 FILM-IDENTIFICATION (DIESEL FUEL) | 1 | |
| 1162433 | 33 FILM-INSTRUCTION (CAT DATA LINK) | 1 | |
| 6V0709 | 34 PLATE-WARNING (RECOIL SPRING) | 2 | |
| 1491337 | 35 FILM-IDENTIFICATION (SERVICE CODES) | 1 | |
| 1166229 | 36 FILM (PROPEL ECM) | 1 | |
| 1166221 | 37 FILM-INFORMATION (CONVEYOR ECM) | 1 | |
| 1234082 | 38 FILM-INFORMATION (HEIGHT SCALE) | 2 | |
| 1354653 | 39 POINTER | 2 | |
| 5P1075 | 40 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P8167 | 41 BOLT (3/8-16X0.625-IN) | 2 | |
| 1072760 | 42 TAG | 2 | |
| 3S2093 | 43 STRAP-CABLE | 2 | |
| 1297682 | 44 FILM (TRANSMISSION OIL DRAIN) | 1 | |
| 1297679 | 45 FILM-INSTRUCTION (ENGINE OIL DRAIN) | 1 | |
| 1296813 | 46 FILM (TOW POINT CYLINDER) | 1 | |
| 7X7644 | 47 FILM-IDENTIFICATION (TIE-DOWN) | 3 |
