System And Components
103-6291 CLUTCH & BRAKE GP-STEERINGS/N HWH1-UP
Group No: 103-6291
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9U9485 | 1 PISTON | 1 | |
| 1233540 | 2 HOUSING-BRAKE | 1 | |
| 1233539 | 3 HUB | 1 | |
| 7T3097 | 4 HUB-INPUT | 1 | |
| 9N4541 | 5 PISTON | 1 | |
| 0S1585 | 6 BOLT (1/2-13X1.5-IN) | 20 | |
| 5P8245 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 27 | |
| 9S8006 | 10 PLUG (7/8-14-THD) | 6 | |
| 2M9780 | 11 SEAL-O-RING | 6 | |
| 3T3601 | 12 RING-SPACER | 1 | |
| 3T4717 | 13 SPRING-DISC | 2 | |
| 3T3602 | 14 RING-SPACER | 1 | |
| 6P5317 | 15 RING-SEAL (EXTERNAL) | 1 | |
| 6T2037 | 16 RING-SEAL | 1 | |
| 8M4389 | 17 SEAL-O-RING | 2 | |
| 4M5858 | 18 BALL BEARING | 1 | |
| 6T0247 | 19 PLATE | 1 | |
| 1A2029 | 20 BOLT (3/8-16X1.125-IN) | 4 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8P4316 | 22 DISC-FRICTION | 8 | |
| 1053372 | 23 SPRING | 1 | |
| 9W8662 | 24 RETAINER AS | 1 | |
| 6T0234 | RETAINER | 1 | |
| 6V0709 | PLATE-WARNING (RECOIL SPRING) | 1 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 4 | |
| 2197239 | 25 SPOOL | 1 | |
| 1067438 | 26 PLATE-BRAKE | 8 | |
| 7T6994 | 27 PLATE-CLUTCH & BRAKE | 5 | |
| 6T0234 | 28 RETAINER | 1 | |
| 2559267 | 29 DISC-FRICTION | 6 | |
| 7T1885 | 30 RING | 1 | |
| 6T0257 | 31 RING-SEAL | 1 | |
| 0L2070 | 32 BOLT (3/8-16X2.25-IN) | 4 | |
| 0S1587 | 33 BOLT (1/2-13X1.75-IN) | 7 | |
| 8F1959 | 34 RING-RETAINING | 1 | |
| 8S3517 | 35 BALL BEARING | 1 | |
| 6T0244 | 36 PLATE | 1 | |
| 9U9484 | 37 RING-SEAL | 1 | |
| 8E1676 | 39 SPRING-CUSHION | 1 | |
| 6T0248 | 40 RING-SEAL | 3 | |
| 5P5297 | 41 RING-RETAINING (EXTERNAL) | 1 | |
| 9U9486 | 42 PLATE-THRUST | 1 | |
| 4F2129 | 43 BALL BEARING | 1 | |
| 1233538 | 44 RETAINER | 1 | |
| 1233542 | 45 SHAFT AS | 1 | |
| 0L1026 | 46 PLUG-CUP | 3 |
