System And Components
6W-8502 SUSPENSION GP-SEATPIN 8ZF1-55
Group No: 6W-8502
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9V3043 | 1 LINK AS | 2 | |
| 9V7943 | 2 SPRING | 2 | |
| 6W8505 | 3 ADJUSTER GP-SEAT | 1 | |
| 8R1883 | 4 ROLLER-GUIDE | 4 | |
| 8R1877 | 5 SPACER (10MM) | 1 | |
| 6W8281 | 6 BUMPER | 2 | |
| 2K9111 | 8 PIN-SPRING | 2 | |
| 4V7872 | 9 KNOB AS-ADJUSTMENT | 1 | |
| 4V7874 | HANDLE AS | 1 | |
| 4V7875 | HANDLE | 1 | |
| 4V7876 | SLEEVE | 1 | |
| 5V1474 | SCREW-FORMING | 1 | |
| 4V7877 | SPRING | 1 | |
| 4V7873 | KNOB | 1 | |
| 4V7877 | SPRING | 1 | |
| 8R1878 | 10 SPACER (35MM) | 1 | |
| 4V7891 | 11 LATCH AS | 1 | |
| 8R1876 | 12 PAD-ROLLER | 4 | |
| 5H3182 | 13 PIN-SPRING | 1 | |
| 4V8565 | 14 INDICATOR | 1 | |
| 4V8610 | 15 SPRING | 1 | |
| 4V8554 | 16 BRACKET | 1 | |
| 0273924 | 17 LOCKNUT | 2 | |
| 1B2693 | 18 BOLT | 2 | |
| 7V5190 | 19 GEAR AS (28 TEETH) | 1 | |
| 8R1884 | 21 SPACER (25MM THK) | 1 | |
| 5V1839 | 22 LOCKNUT | 2 | |
| 4V7884 | 23 BEARING | 2 | |
| 4V8577 | 24 BEARING | 4 | |
| 5V4855 | 25 BOLT | 4 | |
| 4V8606 | 26 HOUSING AS-UPPER | 1 | |
| 1632661 | 27 ARM AS | 1 | |
| 5V4845 | BEARING | 2 | |
| 8Y6957 | 28 SHAFT AS | 2 | |
| 4V8561 | 29 WASHER (0.8MM THK) | 1 | |
| 4B4281 | 30 WASHER (2.5MM THK) | 1 | |
| 4V8562 | 31 PLATE AS | 1 | |
| 4V8566 | 32 GEAR AS (100 TEETH) | 1 | |
| 2K4973 | 34 LOCKNUT (3/8-16 THD) | 4 | |
| 4B4278 | 35 WASHER (1.6MM THK) | 4 | |
| 6W5233 | 36 ABSORBER-SHOCK | 1 | |
| 4V8609 | 37 BOOT | 1 | |
| 4V8556 | 38 BOLT (3/8-16X2.34IN) | 1 | |
| 6D0047 | 39 LOCKNUT | 1 | |
| 9V6754 | 40 FASTENER | 23 | |
| 4V7890 | 41 SPRING | 1 | |
| 4V8264 | 42 LINK | 2 | |
| 6W0590 | 43 LEVER | 1 | |
| 3L1473 | 44 PIN-GROOVED | 1 | |
| 9C2177 | 45 CAP | 1 |
