System And Components
6Y-5809 CLUTCH & BRAKE GP-STEERINGS/N 1FJ4000-4086
Group No: 6Y-5809
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T3601 | 1 RING-SPACER | 1 | |
| 3T3602 | 2 RING-SPACER | 1 | |
| 6T0239 | 3 PISTON | 1 | |
| 6T0257 | 4 RING-SEAL | 1 | |
| 8F1959 | 5 RING-RETAINING | 1 | |
| 8S3517 | 6 BALL BEARING | 1 | |
| 5P5297 | 7 RING-RETAINING (EXTERNAL) | 1 | |
| 7T1885 | 8 RING | 2 | |
| 6T0252 | 9 RING-SEAL | 1 | |
| 6T0243 | 10 PLATE-THRUST | 1 | |
| 6P5317 | 11 RING-SEAL (EXTERNAL) | 1 | |
| 4F2129 | 12 BALL BEARING | 1 | |
| 6T0248 | 13 RING-SEAL | 3 | |
| 8M4438 | 14 SEAL-O-RING | 2 | |
| 8E1842 | 15 RING-SEAL | 1 | |
| 8E1707 | 16 PISTON | 1 | |
| 8E1825 | 17 SPRING-DISC | 1 | |
| 6T0240 | 18 RETAINER | 1 | |
| 6T3080 | 19 PLATE-CLUTCH & BRAKE | 7 | |
| 6Y7946 | 20 DISC-FRICTION | 5 | |
| 6T2979 | 21 HOUSING-BRAKE | 1 | |
| 5S7383 | BOLT (3/8-16X1.75-IN) | 2 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 9S8005 | 23 PLUG (3/4-16-THD) | 3 | |
| 3K0360 | SEAL-O-RING | 3 | |
| 6F6673 | 24 SEAL-O-RING | 3 | |
| 8D4771 | 25 SEAL-O-RING | 1 | |
| 6Y9468 | 26 RETAINER AS | 1 | |
| 6V0709 | PLATE-WARNING (RECOIL SPRING) | 1 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 4 | |
| 0S1585 | 27 BOLT (1/2-13X1.5-IN) | 20 | |
| 5P8245 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 27 | |
| 6T2972 | 29 HOUSING | 1 | |
| 6T2840 | 30 HUB-INPUT | 1 | |
| 0L2070 | 31 BOLT (3/8-16X2.25-IN) | 4 | |
| 6T0244 | 32 PLATE | 1 | |
| 4M5858 | 33 BALL BEARING | 1 | |
| 6Y9373 | 34 DISC-FRICTION | 4 | |
| 0S1587 | 35 BOLT (1/2-13X1.75-IN) | 7 | |
| 8E1874 | 36 RETAINER | 1 | |
| 1A2029 | 37 BOLT (3/8-16X1.125-IN) | 4 | |
| 6T4051 | 38 HUB AS | 1 | |
| 0L1026 | PLUG-CUP | 2 | |
| 6T0247 | 39 PLATE | 1 |
