System And Components
115-9185 TANK GP-FUELS/N 6HK861-UP
Group No: 115-9185
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G0244 | 1 GAUGE GP-FUEL LEVEL (TANK) | 1 | |
| 7V6480 | SCREW-PAN HEAD (6-32X6.35-MM) | 2 | |
| 8C3364 | 2 ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 5D5654 | 11 MOUNTING | 4 | |
| 0S1627 | 12 BOLT (3/4-10X4.5-IN) | 2 | |
| 9D9438 | 13 WASHER (21X111X10-MM THK) | 2 | |
| 1K6870 | 14 LOCKNUT (3/4-10-THD) | 2 | |
| 0L1178 | 15 BOLT (3/4-10X2-IN) | 6 | |
| 6G7803 | 18 VENT AS (FUEL TANK) | 1 | |
| 3008495 | 19 RECEIVER (FAST FILL FUEL) | 1 | |
| 9D0630 | 20 CAP-DUST | 1 | |
| 8W3602 | 21 DEFLECTOR | 1 | |
| 4L6454 | 22 BOLT (3/8-16X1-IN) | 11 | |
| 8T2561 | 23 WASHER-HARD (10.5X28.5X5-MM THK) | 5 | |
| 6V8801 | 24 NUT (3/8-16-THD) | 5 | |
| 8X2232 | 25 SHIM PACK (INCLUDES 8-SHIMS) | 4 | |
| 9M7958 | 26 CLAMP-HOSE | 1 | |
| 1452817 | 27 HOSE AS | 1 | |
| 9M0164 | 28 CLAMP-HOSE | 1 | |
| 8T9101 | 29 BOLT (3/8-16X2.75-IN) | 2 | |
| 8T4896 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 3E7753 | 31 FLOAT AS | 1 | |
| 6V5051 | 32 SEAL-O-RING | 1 | |
| 1162041 | 33 GUARD | 1 | |
| 9P7121 | 34 STRAINER-FUEL (TANK) | 1 | |
| 1159186 | 35 TANK GP-FUEL | 1 | |
| 2462641 | 36 PADLOCK GP (FUEL TANK) | 1 | |
| 5P8500 | KEY (FUEL TANK) | 1 | |
| 6G5294 | 37 CAP | 2 | |
| 9X8887 | 38 BOLT (3/4-10X3-IN) | 4 | |
| 5P8248 | 39 WASHER-HARD (20X36.5X3.5-MM THK) | 12 | |
| 6G7133 | 40 BRACKET AS | 1 | |
| 8D3508 | 40A BOSS (3/8-16X1-IN) | 1 | |
| 1249325 | 41 SENSOR GP-FUEL LEVEL (FUEL TANK) | 1 | |
| 8T2501 | 42 BOLT (3/8-16X2-IN) | 4 | |
| 1366202 | 43 BREATHER AS (FUEL TANK) | 1 | |
| 1050381 | 44 BLOCK | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK) | 1 |
