System And Components
6G-7370 TANK GP-FUELS/N 6HK1-432
Group No: 6G-7370
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T6314 | 1 TANK AS | 1 | |
| 5P8502 | 2 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 8Y6364 | SLEEVE | 1 | |
| 8X2232 | 3 SHIM PACK (INCLUDES 8-SHIMS)(EACH INCLUDES 8 SHIMS) | 4 | |
| 7T2036 | 4 CAP AS-FILLER (FUEL) | 1 | |
| 8P0408 | CAP-FILLER (FUEL TANK) | 1 | |
| 3F4134 | 5 BAFFLE (FUEL TANK FILL CAP) | 1 | |
| 4B5949 | 6 FILTER ELEMENT-FUEL (FUEL CAP)(INNER) | 1 | |
| 4B1663 | 7 FILTER ELEMENT-FUEL (FUEL CAP)(OUTER) | 1 | |
| 4B5423 | 8 GASKET | 1 | |
| 7T2037 | 9 GASKET | 1 | |
| 7B2002 | 10 WASHER (10.2X44.5X3-MM THK) | 1 | |
| 7T2009 | 11 VALVE AS | 1 | |
| 1D4609 | 12 BOLT (3/4-10X3-IN) | 4 | |
| 9P7121 | 13 STRAINER-FUEL | 1 | |
| 0L1178 | 14 BOLT (3/4-10X2-IN) | 6 | |
| 5P8248 | 15 WASHER-HARD (20X36.5X3.5-MM THK) | 12 | |
| 0S1627 | 16 BOLT (3/4-10X4.5-IN) | 2 | |
| 1K6870 | LOCKNUT (3/4-10-THD) | 2 | |
| 6G7133 | 17 BRACKET AS | 1 | |
| 8D3508 | 17A BOSS (3/8-16X1-IN) | 1 | |
| 9D9438 | 18 WASHER (21X111X10-MM THK) | 2 | |
| 5D5654 | 19 MOUNTING | 4 | |
| 3B0551 | 20 PLUG-PIPE | 1 | |
| 1H8306 | SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 8W0652 | 21 SENSOR GP-FUEL LEVEL (FLOAT) | 1 | |
| 2G0244 | GAUGE GP-FUEL LEVEL | 1 | |
| 7V6480 | SCREW-PAN HEAD (6-32X6.35-MM) | 2 | |
| 6G5294 | 22 CAP | 2 | |
| 6G7803 | 23 VENT AS | 1 | |
| 2G9000 | 24 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 9D0630 | 25 CAP-DUST (FUEL TANK) | 1 | |
| 4L6454 | 26 BOLT (3/8-16X1-IN) | 5 | |
| 8T2561 | WASHER-HARD (10.5X28.5X5-MM THK) | 5 | |
| 1D4717 | NUT (3/8-16-THD) | 5 | |
| 8W3602 | 27 DEFLECTOR | 1 | |
| 9M7958 | 28 CLAMP-HOSE | 1 | |
| 0386027 | 29 HOSE AS | 1 | |
| 7D7233 | 30 CLIP (LOOP) | 1 | |
| 5M3062 | 31 BOLT (3/8-16X0.75-IN) | 1 | |
| 8T4896 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK)(FUEL TANK) | 1 |
