System And Components
113-9338 TANK GP-FUELS/N 1HL167-UP
Group No: 113-9338
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1152240 | 1 TANK AS | 1 | |
| 5P8502 | 2 PADLOCK GP | 1 | |
| 5P8500 | KEY | 2 | |
| 8Y6364 | SLEEVE | 1 | |
| 9P7121 | 3 STRAINER-FUEL | 1 | |
| 8T4137 | 4 BOLT (M10X1.5X20-MM) | 1 | |
| 6G7803 | 5 VENT AS | 1 | |
| 2G0244 | 6 GAUGE GP-FUEL LEVEL | 1 | |
| 7V6480 | SCREW-PAN HEAD (6-32X6.35-MM) | 2 | |
| 8W5331 | 7 SENSOR GP-FUEL LEVEL (FLOAT)(FLOAT) | 1 | |
| 2G9000 | 8 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 9D0630 | 9 CAP-DUST (FUEL TANK) | 1 | |
| 1H8306 | 10 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 3B0551 | 11 PLUG-PIPE | 1 | |
| 9M7958 | 12 CLAMP-HOSE | 1 | |
| 0386027 | 13 HOSE AS | 1 | |
| 7D7233 | 14 CLIP (LOOP) | 1 | |
| 7T2036 | 15 CAP AS-FILLER (FUEL) | 1 | |
| 4B1663 | 16 FILTER ELEMENT-FUEL (FUEL CAP)(FUEL TANK CAP) | 1 | |
| 4B5949 | 17 FILTER ELEMENT-FUEL (FUEL CAP)(FUEL TANK CAP) | 1 | |
| 4B5423 | 18 GASKET | 1 | |
| 8P0408 | 19 CAP-FILLER (FUEL TANK) | 1 | |
| 3F4134 | 20 BAFFLE (FUEL TANK FILL CAP) | 1 | |
| 7B2002 | 21 WASHER (10.2X44.5X3-MM THK) | 1 | |
| 7T2009 | 22 VALVE AS | 1 | |
| 7T2037 | 23 GASKET | 1 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 1152241 | 25 PLATE | 1 | |
| 6V5051 | 26 SEAL-O-RING | 1 | |
| 8T4136 | 27 BOLT (M10X1.5X25-MM) | 4 |
