133-3418 TANK GP-FUEL -VIMSS/N 7EK415-640

Group No: 133-3418

Part Number	Part Name	Qty
2G0244	1 GAUGE GP-FUEL LEVEL	1
7V6480	SCREW-PAN HEAD (6-32X6.35-MM)	2
8W5331	2 SENSOR GP-FUEL LEVEL (FLOAT)	1
8T2501	3 BOLT (3/8-16X2-IN)	4
9P7121	4 STRAINER-FUEL (ULTRASONIC)	1
1249325	5 SENSOR GP-FUEL LEVEL	1
5P8502	6 PADLOCK GP (FUEL TANK)	1
5P8500	KEY	1
8Y6364	SLEEVE	1
6G5294	7 CAP	2
5P6712	8 BOLT-LOCKING (3/4-10X3-IN)	4
5P8248	9 WASHER-HARD (20X36.5X3.5-MM THK)	10
8W5364	10 BRACKET AS	1
5D5654	11 MOUNTING	4
1D4614	12 BOLT (3/4-10X5-IN)	2
9D9438	13 WASHER (21X111X10-MM THK)	4
1K6870	14 LOCKNUT (3/4-10-THD)	2
0L1178	15 BOLT (3/4-10X2-IN)	6
6G7803	16 VENT AS	1
3B0551	17 PLUG-PIPE	1
1H8306	18 SCREW-PURGE (1/2-20X1.625-IN)	1
7X0582	19 WASHER-HARD (20X44.5X6-MM THK)	4
2G9000	20 VALVE AS-TANK (FAST FILL FUEL)	1
9D0630	21 CAP-DUST (FUEL TANK)	1
8W3602	22 DEFLECTOR	1
4L6454	23 BOLT (3/8-16X1-IN)	11
8T2561	24 WASHER-HARD (10.5X28.5X5-MM THK)	5
6V8801	25 NUT (3/8-16-THD)	5
8X2232	26 SHIM PACK (INCLUDES 8-SHIMS)	4
9M7958	27 CLAMP-HOSE	1
0386027	28 HOSE AS	1
5M3062	29 BOLT (3/8-16X0.75-IN)	1
8T4896	30 WASHER-HARD (10.2X18.5X2.5-MM THK)	15
7D7233	31 CLIP (LOOP)	1
3E7753	32 FLOAT AS	1
1162041	33 GUARD	1
6V5051	34 SEAL-O-RING	1
7T2036	36 CAP AS-FILLER (FUEL)	1
4B1663	37 FILTER ELEMENT-FUEL (FUEL CAP)	1
4B5949	38 FILTER ELEMENT-FUEL (FUEL CAP)(FUEL)	1
4B5423	39 GASKET	1
8P0408	40 CAP-FILLER (FUEL TANK)	1
3F4134	41 BAFFLE (FUEL TANK FILL CAP)	1
7B2002	42 WASHER (10.2X44.5X3-MM THK)	1
7T2009	43 VALVE AS	1
7T2037	44 GASKET	1
1152500	45 TANK AS	1
5T8645	KIT-VENT (FUEL TANK)(FUEL TANK)	1
