System And Components
133-3419 TANK GP-FUEL -3790-L (1001-US GAL)S/N 7EK415-646
Group No: 133-3419
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T2501 | 1 BOLT (3/8-16X2-IN) | 4 | |
| 6G7803 | 2 VENT AS | 1 | |
| 9M7958 | 3 CLAMP-HOSE | 1 | |
| 0386027 | 4 HOSE AS | 1 | |
| 5M3062 | 5 BOLT (3/8-16X0.75-IN) | 1 | |
| 8T4896 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 7D7233 | 7 CLIP (LOOP) | 1 | |
| 0L1178 | 8 BOLT (3/4-10X2-IN) | 6 | |
| 5P8248 | 9 WASHER-HARD (20X36.5X3.5-MM THK) | 10 | |
| 2G9000 | 10 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 9D0630 | 11 CAP-DUST | 1 | |
| 8W5331 | 12 SENSOR GP-FUEL LEVEL (FLOAT) | 1 | |
| 2G0244 | 13 GAUGE GP-FUEL LEVEL (TANK) | 1 | |
| 7V6480 | SCREW-PAN HEAD (6-32X6.35-MM) | 2 | |
| 9P7121 | 14 STRAINER-FUEL (ULTRASONIC) | 1 | |
| 1249325 | 15 SENSOR GP-FUEL LEVEL | 1 | |
| 5P8502 | 16 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 8Y6364 | SLEEVE | 1 | |
| 5P6712 | 17 BOLT-LOCKING (3/4-10X3-IN) | 4 | |
| 8X2232 | 18 SHIM PACK (INCLUDES 8-SHIMS) | 4 | |
| 6G5294 | 19 CAP | 2 | |
| 6V5051 | 20 SEAL-O-RING | 1 | |
| 1D4614 | 21 BOLT (3/4-10X5-IN) | 2 | |
| 7X0582 | 22 WASHER-HARD (20X44.5X6-MM THK) | 5 | |
| 9D9438 | 23 WASHER (21X111X10-MM THK) | 5 | |
| 5D5654 | 24 MOUNTING | 6 | |
| 1K6870 | 25 LOCKNUT (3/4-10-THD) | 2 | |
| 3B0551 | 26 PLUG-PIPE | 1 | |
| 1H8306 | 27 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 8W3602 | 28 DEFLECTOR | 1 | |
| 4L6454 | 29 BOLT (3/8-16X1-IN) | 11 | |
| 8T2561 | 30 WASHER-HARD (10.5X28.5X5-MM THK) | 5 | |
| 6V8801 | 31 NUT (3/8-16-THD) | 5 | |
| 0S1627 | 32 BOLT (3/4-10X4.5-IN) | 1 | |
| 3E7753 | 33 FLOAT AS | 1 | |
| 1162041 | 34 GUARD | 1 | |
| 1137907 | 35 BRACKET AS | 1 | |
| 8D3508 | 36 BOSS (3/8-16X1-IN) | 1 | |
| 1159170 | 37 TANK AS | 1 | |
| 7T2036 | 42 CAP AS-FILLER (FUEL) | 1 | |
| 4B1663 | 43 FILTER ELEMENT-FUEL (FUEL CAP)(FUEL CAP) | 1 | |
| 4B5949 | 44 FILTER ELEMENT-FUEL (FUEL CAP)(FUEL CAP) | 1 | |
| 4B5423 | 45 GASKET | 1 | |
| 8P0408 | 46 CAP-FILLER (FUEL TANK) | 1 | |
| 3F4134 | 47 BAFFLE (FUEL TANK FILL CAP) | 1 | |
| 7B2002 | 48 WASHER (10.2X44.5X3-MM THK) | 1 | |
| 7T2009 | 49 VALVE AS | 1 | |
| 7T2037 | 50 GASKET | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK)(FUEL TANK) | 1 |
