System And Components
8E-6769 FRAME GP-TELESCOPING RECOIL -RHS/N 7TL1-556
Group No: 8E-6769
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9W9660 | 1 FRAME AS-TRACK ROLLER (FRONT) | 1 | |
| 7T5216 | BUSHING | 1 | |
| 6V0709 | PLATE-WARNING (RECOIL SPRING) | 1 | |
| 4B4158 | SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 1958742 | 2 FRAME AS (RH) | 1 | |
| 1800095 | BAR | 1 | |
| 1938944 | PLATE | 1 | |
| 1938946 | PLATE | 1 | |
| 7T3877 | HOOK | 1 | |
| 7T5993 | PLATE | 1 | |
| 9P5708 | SUPPORT (SLEEVE) | 1 | |
| 1356137 | PLATE | 2 | |
| 1397718 | PLATE | 2 | |
| 9W2380 | 3 RETAINER | 1 | |
| 9W5575 | 4 COVER AS | 1 | |
| 5H6734 | 5 SEAL-O-RING | 1 | |
| 8T8917 | 6 BOLT (1/2-13X1.25-IN) | 4 | |
| 8T4223 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9X4586 | 8 SEAL AS | 1 | |
| 9G0296 | 9 BEARING | 1 | |
| 9G7516 | 10 PLUG | 16 | |
| 6T8801 | 11 GUIDE AS | 2 | |
| 6T8258 | FILM-WARNING (RECOIL SPRING) | 1 | |
| 6P8931 | 12 COVER | 2 | |
| 2K4472 | 13 SEAL-O-RING | 2 | |
| 8T4122 | 14 WASHER-HARD (17X32X3.5-MM THK) | 12 | |
| 7X0345 | 15 BOLT (5/8-11X1.75-IN) | 12 | |
| 9P7053 | 16 PLATE-THRUST | 1 | |
| 4D4508 | 17 SEAL-O-RING | 1 | |
| 8T0208 | 18 SEAL-PIVOT SHAFT | 1 | |
| 4T2069 | 19 PLUG-DRAIN | 3 | |
| 2H3932 | 20 SEAL-O-RING | 3 | |
| 8E2819 | 21 RING-RETAINING | 1 | |
| 7G9709 | 22 BUSHING | 1 | |
| 7T4132 | 23 RING-THRUST | 1 | |
| 6Y0210 | 24 BUSHING | 1 | |
| 3T7920 | 25 SLEEVE | 1 | |
| 6T8258 | 26 FILM-WARNING (RECOIL SPRING) | 2 | |
| 7T8004 | 27 RING-RETAINING | 1 | |
| 9F2247 | PLUG-PIPE (1/8-27-THD) | 2 |
