System And Components
118-2252 TANK & MTG GP-FUELS/N 7KK40-UP
Group No: 118-2252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8X9005 | 1 TANK GP-FUEL | 1 | |
| 1172233 | 2 HANDRAIL | 2 | |
| 8T4139 | 3 BOLT (M12X1.75X30-MM) | 4 | |
| 5P1076 | 4 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 1172234 | 5 HANDRAIL | 2 | |
| 1172231 | 6 BRACKET AS | 4 | |
| 4E1063 | MOUNT-FLEXIBLE | 1 | |
| 7X2476 | 7 BOLT (M24X3X220-MM) | 4 | |
| 6V7676 | 8 NUT (M24X3-THD) | 4 | |
| 8T4167 | 9 WASHER-HARD (26X44X4-MM THK) | 8 | |
| 7X2563 | 10 BOLT (M20X2.5X60-MM) | 8 | |
| 8T4123 | 11 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 2175703 | 14 RECEIVER (FAST FILL FUEL) | 1 | |
| 9D0630 | 15 CAP-DUST | 1 | |
| 1380736 | 16 TUBE AS | 1 | |
| 1P3707 | 17 SEAL-RECTANGULAR | 1 | |
| 4D5980 | 18 GROMMET | 1 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4910 | 20 BOLT (M12X1.75X60-MM) | 4 |
