System And Components
8X-9005 TANK GP-FUELS/N 7KK1-39
Group No: 8X-9005
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1172200 | 1 TANK AS | 1 | |
| 2G9000 | 2 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 9D0630 | 3 CAP-DUST | 1 | |
| 1H8306 | 4 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 3B0551 | 5 PLUG-PIPE | 1 | |
| 1249325 | 6 SENSOR GP-FUEL LEVEL (ULTRASONIC) | 1 | |
| 3E7753 | 7 FLOAT AS | 1 | |
| 6V5051 | 8 SEAL-O-RING | 1 | |
| 1018909 | 9 CAP AS-FILLER | 1 | |
| 9X8600 | SEAL-O-RING | 1 | |
| 1172227 | 10 DOOR AS | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4185 | 12 BOLT (M10X1.5X50-MM) | 4 | |
| 7K1181 | 13 STRAP-CABLE | 2 | |
| 8T4137 | 14 BOLT (M10X1.5X20-MM) | 12 | |
| 9S4185 | 15 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 16 SEAL-O-RING | 1 | |
| 8W5658 | 17 HOSE | 1 | |
| 9M2904 | 18 CLAMP-HOSE | 1 | |
| 7D7233 | 19 CLIP (LOOP) | 2 | |
| 9S4191 | 20 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 21 SEAL-O-RING | 1 | |
| 5V6106 | 22 VENT AS | 1 | |
| 9P7121 | 23 STRAINER-FUEL | 1 | |
| 5P8502 | 24 PADLOCK GP | 3 | |
| 5P8500 | KEY | 1 | |
| 8Y6364 | SLEEVE | 1 | |
| 1295453 | 25 DOOR AS | 1 | |
| 0065707 | 26 ELBOW-PIPE | 1 | |
| 9F0440 | 27 PIPE | 1 | |
| 3B6491 | 28 COUPLING-PIPE | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK) | 1 |
