System And Components
114-0937 TANK GP-FUELS/N 3PR428-UP
Group No: 114-0937
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M0164 | 1 CLAMP-HOSE | 1 | |
| 9P7121 | 2 STRAINER-FUEL (TANK) | 1 | |
| 6G5294 | 3 CAP | 2 | |
| 9X8887 | 4 BOLT (3/4-10X3-IN) | 4 | |
| 5P8248 | 5 WASHER-HARD (20X36.5X3.5-MM THK) | 6 | |
| 8T4896 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1087919 | 7 BRACKET AS | 1 | |
| 0S1585 | 8 BOLT (1/2-13X1.5-IN) | 4 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 0S1627 | 10 BOLT (3/4-10X4.5-IN) | 2 | |
| 1K6870 | 11 LOCKNUT (3/4-10-THD) | 2 | |
| 9D9438 | 12 WASHER (21X111X10-MM THK) | 2 | |
| 5D5654 | 13 MOUNTING | 4 | |
| 6G7803 | 14 VENT AS (FUEL TANK) | 1 | |
| 5P8502 | 15 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 8Y6364 | SLEEVE | 1 | |
| 9D0630 | 16 CAP-DUST (FAST FILL FUEL ADAPTER) | 1 | |
| 2G9000 | 17 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 5P2230 | 18 CLAMP-HOSE | 1 | |
| 1390156 | 19 HOSE AS | 1 | |
| 8T9101 | 20 BOLT (3/8-16X2.75-IN) | 1 | |
| 1146352 | 21 TANK AS-FUEL | 1 | |
| 1H8306 | 22 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 3B0551 | 23 PLUG-PIPE (DRAIN) | 1 | |
| 2121439 | 24 SENDER GP-FUEL LEVEL | 1 | |
| 4H9027 | 25 PLUG-PIPE | 2 | |
| 7T2036 | 26 CAP AS-FILLER (FUEL) | 1 | |
| 4B1663 | 27 FILTER ELEMENT-FUEL (FUEL CAP)(TANK CAP) | 1 | |
| 4B5949 | 28 FILTER ELEMENT-FUEL (FUEL CAP)(FUEL TANK CAP) | 1 | |
| 4B5423 | 29 GASKET | 1 | |
| 8P0408 | 30 CAP-FILLER (FUEL TANK) | 1 | |
| 3F4134 | 31 BAFFLE (FUEL TANK FILL CAP) | 1 | |
| 7B2002 | 32 WASHER (10.2X44.5X3-MM THK) | 1 | |
| 7T2009 | 33 VALVE AS | 1 | |
| 7T2037 | 34 GASKET | 1 | |
| 5P6459 | 35 GROMMET | 1 | |
| 8X4575 | 36 FILTER AS-BREATHER (FUEL TANK) | 1 | |
| 1050381 | 37 BLOCK | 1 | |
| 6V8400 | 38 SEAL-O-RING | 1 | |
| 7M8485 | 39 SEAL-O-RING | 1 | |
| 8C3364 | 40 ELBOW | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK)(FUEL TANK) | 1 |
