127-0559 HOOD GP-TRUCKS/N 4AR1-UP

Group No: 127-0559
Part NumberPart NameQty
8T42441 NUT (M12X1.75-THD)4
7G88392 SPACER (13.5X57X6-MM THK)4
7X0590WASHER-HARD (13.5X44.5X6-MM THK)2
8T41363 BOLT (M10X1.5X25-MM)10
8T4222WASHER-PLATED (11X32X2.5-MM THK)10
8T49564 BOLT (M12X1.75X35-MM)2
5T72615 HOOD AS1
9D84546 BRACKET1
7D86357 RIVET14
9M2307WASHER (5.2X19X2-MM THK)14
2G95068 BRACKET3
16634149 HINGE1
5T726410 HOOD AS1
2G950611 BRACKET1
7D863512 RIVET14
9M2307WASHER (5.2X19X2-MM THK)14
9D845413 BRACKET1
6G126214 HANDHOLD AS1
5G081715 BUMPER-CONICAL1
6V8186NUT-FULL (5/16-24-THD)1
8T4224WASHER-HARD (8.8X16X2-MM THK)1
7T833116 MOUNT AS2
8T6868BOLT (M12X1.75X80-MM)2
5P107617 WASHER-HARD (13.5X30X4-MM THK)2
126727718 HOOD AS1
8T349019 NUT-WELD (M10X1.5-THD)20
8T359720 NUT-WELD (M12X1.75-THD)10
7I580021 BRACKET AS1
8T413322 NUT (M10X1.5-THD)27
8T412123 WASHER-HARD (11X21X2.5-MM THK)28
8T419624 BOLT (M10X1.5X35-MM)10
8T420525 WASHER-HARD (7.2X14.5X2-MM THK)15
3B460726 PIN-COTTER5
2M5795PIN-CLEVIS5
9M276027 ANCHOR5
5C955328 BOLT (M6X1X16-MM)10
5C2890NUT (M6X1-THD)10
9M383729 BRACKET-CATCH5
9M383530 LATCH-RUBBER5
8X441631 BRACKET AS1
8T349032 NUT-WELD (M10X1.5-THD)4
8T413633 BOLT (M10X1.5X25-MM)20
1P092634 GUARD AS-CONTROL1
8W463735 HINGE1
8T418236 BOLT (M10X1.5X45-MM)14
8T4222WASHER-PLATED (11X32X2.5-MM THK)14
103068737 SUPPORT AS1
6V963238 NUT-WELD (M6X1-THD)4
5V0120BAR2
8T413739 BOLT (M10X1.5X20-MM)4
7X772940 WASHER (11X25X3-MM THK)6
