System And Components
130-7957 SERVICE CENTER GPS/N 4AR103-217
Group No: 130-7957
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1232993 | 1 SWITCH GP-LIQUID LEVEL (FLUID COMPARTMENT) | 4 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2M9780 | 2 SEAL-O-RING | 6 | |
| 1160118 | 3 CLIP | 2 | |
| 1344628 | 4 HOSE AS | 1 | |
| 7D8793 | 5 ELBOW-FLARED | 1 | |
| 2P7212 | 6 ELBOW-UNION | 1 | |
| 2P1279 | 7 LOCKNUT (9/16-18-THD) | 1 | |
| 4D7794 | 8 CLIP | 6 | |
| 0338248 | 9 CLIP (LOOP) | 19 | |
| 8T4137 | 10 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 23 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 13 | |
| 2F1336 | 13 FITTING-HEAD | 1 | |
| 1307858 | 14 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 13 | |
| 5K9090 | 15 SEAL-O-RING | 3 | |
| 1307844 | 16 HOSE AS | 1 | |
| 3D2824 | 17 SEAL-O-RING | 3 | |
| 6V9007 | 18 ELBOW | 1 | |
| 1338716 | 19 BLOCK | 4 | |
| 8M2773 | 20 CLIP (LOOP) | 2 | |
| 1406353 | 21 PLATE | 4 | |
| 8T5005 | 22 BOLT (M10X1.5X70-MM) | 4 | |
| 4D1432 | 23 SPACER (12.52X17.14X45.72-MM THK) | 4 | |
| 0100742 | 24 SCREW-MACHINE (6-32X1-IN) | 2 | |
| 4B5324 | 25 WASHER (3.9X9.6X1.2-MM THK) | 2 | |
| 9B1117 | 26 LOCKWASHER | 2 | |
| 4B2041 | 27 NUT (6-32-THD) | 2 | |
| 6G4195 | 28 SWITCH AS-LIMIT | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6V8373 | SCREW-MACHINE (6-32X0.187-IN) | 3 | |
| 1068800 | 29 PLATE | 1 | |
| 5C2890 | 30 NUT (M6X1-THD) | 2 | |
| 9X8256 | 31 WASHER (6.6X12X2-MM THK) | 4 | |
| 5C9553 | 32 BOLT (M6X1X16-MM) | 2 | |
| 1307855 | 33 HARNESS AS | 1 | |
| 1307854 | 34 HARNESS AS-PLATFORM (RH) | 1 | |
| 1S6420 | 35 CLIP | 1 | |
| 5K3294 | 36 CLIP | 1 | |
| 1307852 | 37 HOSE AS | 1 | |
| 8T4139 | 38 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 3S8664 | 40 CLIP | 9 | |
| 1455676 | 41 HARNESS AS | 1 | |
| 5P7854 | 42 CLIP (LOOP) | 1 | |
| 7D7233 | 43 CLIP (LOOP) | 5 | |
| 1307845 | 44 ADAPTER | 1 | |
| 6V9746 | 45 SEAL-O-RING | 3 | |
| 6V9853 | 46 ELBOW | 1 | |
| 1307850 | 47 HOSE AS | 1 | |
| 6V8635 | 48 CONNECTOR | 2 | |
| 7M8485 | 49 SEAL-O-RING | 2 | |
| 6V9854 | 50 ELBOW (SWIVEL) | 1 | |
| 6V9837 | 51 TEE-SWIVEL | 2 | |
| 6V8398 | 52 SEAL-O-RING | 8 | |
| 5P7468 | 53 CLIP (SLOT) | 3 | |
| 6V0545 | 54 GROMMET | 3 | |
| 5P7469 | 55 CLIP (TAB) | 3 | |
| 7X7729 | 56 WASHER (11X25X3-MM THK) | 3 | |
| 1307847 | 57 HOSE AS | 1 | |
| 9X8250 | 58 CLIP (LOOP) | 2 | |
| 8T4133 | 59 NUT (M10X1.5-THD) | 2 | |
| 1093001 | 60 STUD-TAPERLOCK (M10X1.5X65-MM) | 2 | |
| 1307848 | 61 HOSE AS | 1 | |
| 1307860 | 62 BOX AS | 1 | |
| 2G9524 | LATCH | 2 | |
| 4E9919 | HINGE | 2 | |
| 1307868 | COVER | 1 | |
| 9D1829 | 63 CLIP | 3 | |
| 1307864 | 64 PLATE-IDENTIFICATION | 1 | |
| 6V8637 | 65 CONNECTOR | 2 | |
| 2P1286 | 66 LOCKNUT-BULKHEAD (1-5/16-12-THD) | 2 | |
| 1108319 | 67 FITTING AS (QUICK DISCONNECT, FEMALE) | 2 | |
| 1108318 | CAP-DUST | 1 | |
| 6V8638 | 68 CONNECTOR | 2 | |
| 2P1293 | 69 LOCKNUT (1-3/16-12-THD) | 2 | |
| 1180164 | 70 FITTING AS (QUICK DISCONNECT) | 2 | |
| 1180163 | CAP | 1 | |
| 4W4076 | 71 ELBOW | 1 | |
| 9D3127 | 72 BASE AS-INDICATOR LIGHT | 9 | |
| 9D2867 | 73 LENS-AMBER | 9 | |
| 7N5876 | 74 LAMP (24-VOLT, 0.2-AMPERE) | 9 | |
| 6T6969 | 75 GUARD-SWITCH | 1 | |
| 8C9812 | 76 SWITCH AS-TOGGLE (FLUID LEVEL TEST) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 0396360 | 77 RIVET | 8 | |
| 8T4195 | 78 BOLT (M10X1.5X30-MM) | 4 | |
| 2G9000 | 79 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 9D0630 | 80 CAP-DUST | 1 | |
| 8T3611 | 81 CONNECTOR | 1 | |
| 2S4078 | 82 SEAL-O-RING | 2 | |
| 2V2043 | 83 NUT-BULKHEAD (1-5/8-12-THD) | 1 | |
| 1108827 | 84 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 1108826 | CAP-DUST | 1 | |
| 6V9875 | 85 CONNECTOR | 1 | |
| 1178568 | 86 NUT-BULKHEAD (1-7/8-12-THD) | 1 | |
| 1180166 | 87 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 1180165 | CAP-DUST | 1 | |
| 6V0545 | 88 GROMMET | 3 | |
| 5P7469 | 89 CLIP (TAB) | 3 | |
| 5P7468 | 90 CLIP (SLOT) | 3 | |
| 8T4223 | 91 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 8T4139 | 92 BOLT (M12X1.75X30-MM) | 7 | |
| 5K3294 | 93 CLIP | 5 | |
| 8T4956 | 94 BOLT (M12X1.75X35-MM) | 1 | |
| 8W7216 | 95 BAR | 1 | |
| 8T4183 | 96 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4244 | 97 NUT (M12X1.75-THD) | 1 | |
| 0338248 | 98 CLIP (LOOP) | 1 | |
| 8T4137 | 99 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4121 | 100 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 1307846 | 101 HOSE AS | 1 | |
| 6V8400 | 102 SEAL-O-RING | 2 | |
| 1307857 | 103 GROMMET | 2 | |
| 1307856 | 104 PLATE | 2 | |
| 6V9009 | 105 ELBOW | 1 | |
| 2S4078 | 106 SEAL-O-RING | 1 | |
| 6V9746 | 107 SEAL-O-RING | 2 | |
| 1307849 | 108 HOSE AS | 1 | |
| 8D9947 | 109 CLIP | 4 | |
| 7M8485 | 110 SEAL-O-RING | 1 | |
| 6V9008 | 111 ELBOW (90-DEG) | 1 | |
| 5K9090 | 112 SEAL-O-RING | 2 | |
| 1307851 | 113 HOSE AS | 1 | |
| 7D4092 | 114 CLIP | 2 | |
| 1232993 | 115 SWITCH GP-LIQUID LEVEL | 4 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2M9780 | 116 SEAL-O-RING | 4 | |
| 4K8864 | 117 CLIP (LOOP) | 2 | |
| 8T4136 | 118 BOLT (M10X1.5X25-MM) | 10 |
