System And Components
142-7173 SERVICE CENTER GPS/N 4AR218-UP
Group No: 142-7173
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8635 | 3 CONNECTOR | 2 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 7M8485 | SEAL-O-RING | 2 | |
| 1307845 | 4 ADAPTER | 1 | |
| 1683303 | 6 HOSE AS | 1 | |
| 6V9008 | 7 ELBOW (90-DEG) | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 7D7233 | 9 CLIP (LOOP) | 6 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 20 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 40 | |
| 2G9000 | 12 VALVE AS-TANK (FAST FILL FUEL) | 1 | |
| 9D0630 | 13 CAP-DUST | 1 | |
| 1138583 | 14 CONNECTOR | 1 | |
| 1683305 | 16 HOSE AS | 1 | |
| 6V9009 | 17 ELBOW | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5P7468 | 19 CLIP (SLOT) | 6 | |
| 5P7469 | 20 CLIP (TAB) | 6 | |
| 6V0545 | 21 GROMMET | 6 | |
| 1180164 | 22 FITTING AS (QUICK DISCONNECT) | 2 | |
| 1180163 | CAP | 1 | |
| 6V8633 | 24 CONNECTOR | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 2M9780 | 25 SEAL-O-RING | 8 | |
| 1683304 | 26 HOSE AS | 1 | |
| 1683302 | 27 HOSE AS | 1 | |
| 6V9837 | 28 TEE-SWIVEL | 2 | |
| 6V8398 | SEAL-O-RING | 4 | |
| 1108319 | 30 FITTING AS (QUICK DISCONNECT, FEMALE) | 2 | |
| 1108318 | CAP-DUST | 1 | |
| 6V8637 | 32 CONNECTOR | 2 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1307849 | 34 HOSE AS | 1 | |
| 6V9004 | 35 ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1307850 | 37 HOSE AS | 1 | |
| 6V9853 | 38 ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 5P7854 | 39 CLIP (LOOP) | 1 | |
| 1180166 | 40 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 1180165 | CAP-DUST | 1 | |
| 6V9875 | 42 CONNECTOR | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 1307851 | 43 HOSE AS | 1 | |
| 9D1829 | 44 CLIP | 3 | |
| 4W4076 | 45 ELBOW | 1 | |
| 1307852 | 46 HOSE AS | 1 | |
| 2P7212 | 47 ELBOW-UNION | 1 | |
| 2P1279 | 48 LOCKNUT (9/16-18-THD) | 1 | |
| 1344628 | 49 HOSE AS | 1 | |
| 1S6420 | 50 CLIP | 1 | |
| 7D8793 | 51 ELBOW-FLARED | 1 | |
| 3S8664 | 52 CLIP | 8 | |
| 1843054 | 53 HARNESS AS | 1 | |
| 1307854 | 54 HARNESS AS-PLATFORM (RH) | 1 | |
| 1307855 | 55 HARNESS AS | 1 | |
| 0338248 | 57 CLIP (LOOP) | 15 | |
| 4D7794 | 58 CLIP | 7 | |
| 5K3294 | 59 CLIP | 6 | |
| 4K8864 | 60 CLIP (LOOP) | 2 | |
| 7K1181 | 61 STRAP-CABLE | 20 | |
| 1461761 | 62 PLATE AS | 1 | |
| 1307856 | 63 PLATE | 1 | |
| 1307857 | 64 GROMMET | 1 | |
| 1669221 | 65 BOX AS | 1 | |
| 2G9524 | LATCH | 2 | |
| 4E9919 | HINGE | 2 | |
| 8T4195 | 66 BOLT (M10X1.5X30-MM) | 4 | |
| 0396360 | 68 RIVET | 8 | |
| 9D3127 | 69 BASE AS-INDICATOR LIGHT | 9 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 9D2867 | 70 LENS-AMBER | 9 | |
| 1631883 | 71 LAMP-INDICATOR (24-VOLT) | 9 | |
| 8C9812 | 72 SWITCH AS-TOGGLE (INDICATOR TEST) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 6T6969 | 73 GUARD-SWITCH | 1 | |
| 1338716 | 74 BLOCK | 4 | |
| 1406353 | 75 PLATE | 4 | |
| 1409473 | 76 STUD-TAPERLOCK (M10X1.5X100-MM) | 4 | |
| 4D1432 | 77 SPACER (12.52X17.14X45.72-MM THK) | 4 | |
| 8M2773 | 78 CLIP (LOOP) | 2 | |
| 7D4092 | 79 CLIP | 2 | |
| 8D9947 | 80 CLIP | 3 | |
| 8T4139 | 81 BOLT (M12X1.75X30-MM) | 7 | |
| 8T4223 | 82 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 1068800 | 83 PLATE | 1 | |
| 5C9553 | 84 BOLT (M6X1X16-MM) | 2 | |
| 9X8256 | 85 WASHER (6.6X12X2-MM THK) | 4 | |
| 5C2890 | 86 NUT (M6X1-THD) | 2 | |
| 6G4195 | 87 SWITCH AS-LIMIT (AUTO LUBE) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6V8373 | SCREW-MACHINE (6-32X0.187-IN) | 3 | |
| 0100742 | 88 SCREW-MACHINE (6-32X1-IN) | 2 | |
| 4B5324 | 89 WASHER (3.9X9.6X1.2-MM THK) | 2 | |
| 9B1117 | 90 LOCKWASHER | 2 | |
| 4B2041 | 91 NUT (6-32-THD) | 2 | |
| 9X8250 | 92 CLIP (LOOP) | 2 | |
| 8T4137 | 93 BOLT (M10X1.5X20-MM) | 10 | |
| 8T4133 | 94 NUT (M10X1.5-THD) | 9 | |
| 2F1336 | 95 FITTING-HEAD | 1 | |
| 7X7729 | 96 WASHER (11X25X3-MM THK) | 7 | |
| 1093001 | 97 STUD-TAPERLOCK (M10X1.5X65-MM) | 5 | |
| 8T4956 | 98 BOLT (M12X1.75X35-MM) | 1 | |
| 8W7216 | 99 BAR | 1 | |
| 8T4183 | 100 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4244 | 101 NUT (M12X1.75-THD) | 1 | |
| 1160118 | 102 CLIP | 3 | |
| 6V9854 | 103 ELBOW (SWIVEL) | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 4D5371 | 106 CLIP | 1 | |
| 4P7581 | 108 CLIP (LADDER) | 3 | |
| 3S2093 | 109 STRAP-CABLE | 6 | |
| 1669229 | 110 COVER | 1 | |
| 6Y2349 | 111 CONNECTOR | 5 | |
| 3D2824 | SEAL-O-RING | 10 | |
| 5P1042 | 112 ADAPTER-O-RING | 2 | |
| 2M9780 | SEAL-O-RING | 2 | |
| 6V0301 | 113 ADAPTER | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C9029 | 114 UNION | 1 | |
| 7M8485 | SEAL-O-RING | 2 | |
| 7X2470 | 115 ADAPTER | 1 | |
| 2S4078 | SEAL-O-RING | ||
| 1S1015 | 116 CLIP (LOOP) | 1 | |
| 2T3019 | 117 CLIP (LOOP) | 1 | |
| 8T4179 | 118 BOLT (M12X1.75X20-MM) | 2 | |
| 5P1076 | 119 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 1232993 | 120 SWITCH GP-LIQUID LEVEL (STEERING TANK) | 1 | |
| 1232993 | 121 SWITCH GP-LIQUID LEVEL (WATER TANK) | 2 | |
| 1232993 | 122 SWITCH GP-LIQUID LEVEL (HYDRAULIC TANK) | 4 | |
| 1232993 | 123 SWITCH GP-LIQUID LEVEL (OIL PAN) | 1 |
