System And Components
250-0398 AIR CONDITIONER GPS/N 5111-UP
Group No: 250-0398
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2R8159 | 1 BOLT-SOCKET HEAD (10-32X1.5-IN) | 2 | |
| 0374838 | 2 CLAMP | 1 | |
| 1338714 | 3 GROMMET | 1 | |
| 1776687 | 4 COIL AS-HEATER | 1 | |
| 1776689 | 5 PLATE | 1 | |
| 1776690 | 6 PLATE | 1 | |
| 1776692 | 7 PLATE | 1 | |
| 1776694 | 8 PLATE | 1 | |
| 1776696 | 9 GROMMET | 2 | |
| 1776698 | 10 GASKET | 4 | |
| 1776700 | 11 TUBE-DRAIN | 2 | |
| 1776701 | 12 GASKET | 1 | |
| 1776707 | 13 HOUSING | 1 | |
| 1776708 | 14 COVER | 1 | |
| 1776710 | 15 RING | 1 | |
| 1776726 | 16 TUBE | 1 | |
| 1776727 | 17 ACTUATOR | 1 | |
| 3201457 | 18 DOOR AS | 1 | |
| 1776733 | 19 DOOR AS | 1 | |
| 1794673 | 20 GASKET | 1 | |
| 1794674 | 21 GASKET | 1 | |
| 1794682 | 22 LEVER | 2 | |
| 1794683 | 23 ROD | 1 | |
| 1796136 | 24 GASKET | 1 | |
| 1877719 | 25 SCREW-HEX FLANGE (M5X2.24X14-MM) | 30 | |
| 1892456 | 26 CLIP | 5 | |
| 1910979 | 27 WHEEL-BLOWER | 1 | |
| 1930702 | 28 GASKET | 1 | |
| 2289043 | 29 COIL AS-EVAPORATOR | 1 | |
| 2289044 | 30 VALVE (EXPANSION) | 1 | |
| 2881556 | 31 MOTOR AS-FAN | 1 | |
| 2289539 | 32 PLATE | 1 | |
| 2844177 | 33 TUBE AS | 1 | |
| 2516773 | 34 BRACKET | 1 | |
| 4B4274 | 35 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 5C2890 | 36 NUT (M6X1-THD) | 1 | |
| 8T4205 | 37 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 9X7380 | 38 SEAL-O-RING | 1 | |
| 9X7381 | 39 SEAL-O-RING | 1 | |
| 9X7382 | 40 SEAL-O-RING | 2 |
