System And Components
148-4598 DRIVE GP-SWINGS/N BKF1-UP; BLY1-UP
Group No: 148-4598
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1484602 | 1 GEAR-PLANETARY (24-TEETH) | 4 | |
| 0941528 | 2 WASHER (53X84X1-MM THK) | 8 | |
| 1484608 | 3 SHAFT-PLANETARY | 4 | |
| 1912525 | 4 COVER-HOUSING | 1 | |
| 1484600 | 5 GEAR-SUN (17-TEETH) | 1 | |
| 7I7684 | 6 SPACER (50X79.6X6-MM THK) | 2 | |
| 1994680 | 7 GAUGE-OIL LEVEL (SWING DRIVE) | 1 | |
| 1994678 | 8 PIPE AS | 1 | |
| 0961441 | 9 RING-RETAINING | 1 | |
| 0931730 | 10 RING-RETAINING | 1 | |
| 1484601 | 11 GEAR-SUN (17-TEETH) | 1 | |
| 1912511 | 12 CARRIER-PLANETARY | 1 | |
| 1141322 | 13 RING-RETAINING | 1 | |
| 1484607 | 14 CARRIER-PLANETARY | 1 | |
| 1484604 | 15 GEAR-RING (67-TEETH) | 1 | |
| 1U8846 | 17 SEALANT-GASKET | ||
| 1107149 | 18 RING-RETAINING | 1 | |
| 9U8693 | 19 BEARING-ROLLER | 1 | |
| 6V7238 | 20 VALVE-SHUTOFF | 1 | |
| 3K0360 | 21 SEAL-O-RING | 1 | |
| 7I7619 | 22 BEARING-ROLLER | 1 | |
| 1289170 | 23 SEAL-LIP TYPE | 2 | |
| 1994496 | 24 SHAFT-PINION | 1 | |
| 7I7611 | 25 CAGE | 1 | |
| 8T4183 | 26 BOLT (M12X1.75X40-MM) | 10 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 5M4454 | 28 SEAL-O-RING | 1 | |
| 1912524 | 29 HOUSING | 1 | |
| 1484611 | 30 WASHER (71.3X112X1-MM THK) | 8 | |
| 1912514 | 31 BEARING AS | 8 | |
| 1484609 | 32 SHAFT-PLANETARY | 4 | |
| 1484603 | 33 GEAR-PLANETARY (24-TEETH) | 4 | |
| 0995194 | 34 PIN-SPRING | 8 | |
| 8T6383 | 35 BOLT (M16X2X200-MM) | 24 | |
| 9X8257 | 36 WASHER (17.5X30X3.5-MM THK) | 24 | |
| 1912513 | 37 BEARING AS-ROLLER | 4 | |
| 2316864 | 38 BREATHER AS (SWING DRIVE) | 1 | |
| 0935150 | COUPLING-PIPE | 1 | |
| 1148234 | BREATHER (SWING DRIVE) | 1 | |
| 2316969 | NIPPLE-PIPE | 1 | |
| 1719413 | 39 SPACER (140.5X160X103.2-MM THK) | 1 | |
| 1994672 | 40 CONNECTOR AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 |
