System And Components
217-9689 DRIVE AR-SWINGS/N 1031-UP
Group No: 217-9689
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1652273 | 1 VALVE AS-SHUTOFF (SWING DRIVE OIL DRAIN) | 1 | |
| 6V7238 | VALVE-SHUTOFF | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 2B7561 | 2 CORK | 2 | |
| 5D1026 | 3 CLAMP-BAND | 2 | |
| 0964755 | 4 PIN | 1 | |
| 2208623 | 5 DRIVE GP-SWING | 1 | |
| 2215390 | 6 HOSE AS | 1 | |
| 2215391 | 7 HOSE AS | 1 | |
| 5P0767 | 8 HOSE (76-CM) | ||
| 1P3702 | 9 SEAL-RECTANGULAR | 4 | |
| 1689860 | 10 PLUG | 1 | |
| 1123929 | 11 BOLT (M24X3X100-MM) | 16 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 7Y0336 | 13 SPACER (24.5X44X24-MM THK) | 16 | |
| 8T9403 | 14 FLANGE-HALF | 8 | |
| 8T4182 | 15 BOLT (M10X1.5X45-MM) | 16 | |
| 1U8846 | SEALANT-GASKET |
