System And Components
359-9143 FILTER GP-FUELType 1
Group No: 359-9143
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 5 | |
| 6N1127 | 2 SHIELD | 1 | |
| 8T9655 | 3 MOUNT-ISOLATION | 8 | |
| 1236948 | 4 PLUG | 1 | |
| 1418275 | 5 VALVE-DRAIN (FUEL)(FUEL FILTER) | 1 | |
| 1601744 | 6 BRACKET | 2 | |
| 1911782 | 7 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 1978391 | 8 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2066876 | 9 CAP-TUBE | 1 | |
| 2134740 | 10 PUMP GP-FUEL PRM & WATER SEP | 1 | |
| 2321374 | 11 BRACKET | 1 | |
| 2321376 | 12 SPACER (8.5X12.7X139.1-MM THK) | 2 | |
| 2379309 | 13 BASE AS | 1 | |
| 2379323 | STUD | 1 | |
| 2495294 | 14 HARNESS AS-SENSOR | 1 | |
| 9X1386 | SLEEVE (45-CM) | ||
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1945226 | TERMINAL AS (16-GA) | 6 | |
| 1945227 | TERMINAL AS (14-GA) | 6 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2696436 | 15 HARNESS AS-SENSOR (FUEL) | 1 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1148843 | SLEEVE-PLASTIC (40-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 2769067 | 16 SENSOR GP-PRESSURE (ENGINE OIL)(FUEL) | 1 | |
| 4233827 | 17 HOSE AS | 1 | |
| 4233829 | 18 HOSE AS | 2 | |
| 0L1351 | 19 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 5 | |
| 0S1591 | 21 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 1 | |
| 0T0102 | 23 BOLT (3/8-16X0.625-IN) | 2 | |
| 2098441 | 24 HARNESS AS-PUMP (FUEL PRIMING) | 1 | |
| 1833407 | 25 PLUG AS | 2 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1D4539 | 26 BOLT (5/16-18X2.5-IN) | 1 | |
| 3510258 | 27 ELBOW AS | 1 | |
| 1R0755 | 28 FILTER-FUEL (ADVANCED EFFICIENCY) | 1 | |
| 9X0262 | 29 ADAPTER | 1 | |
| 2147568 | 30 SEAL-O-RING | 1 | |
| 2287091 | 31 SEAL-O-RING | 1 | |
| 2385080 | 32 SEAL-O-RING | 1 | |
| 2385081 | 33 SEAL-O-RING | 2 | |
| 3072673 | 34 PLUG AS | 2 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3095131 | 35 PLUG AS | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3133492 | 36 PLUG AS | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3218654 | 37 ADAPTER AS | 1 | |
| 3P1932 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3295459 | 38 ADAPTER AS | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3353974 | 39 FITTING AS | 1 | |
| 7W7381 | FITTING-OUTLET | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4F3508 | 40 BOLT (5/16-18X6.5-IN) | 2 | |
| 4P7581 | 41 CLIP (LADDER) | 3 | |
| 4P8134 | 42 CLIP (LADDER) | 2 | |
| 5M2894 | 43 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 5P9085 | 44 CLIP (LOOP) | 1 | |
| 5P9297 | 45 CLIP (LOOP) | 5 | |
| 3866213 | 46 CONNECTOR AS | 1 | |
| 6K3607 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 6M7476 | 47 ELBOW | 1 | |
| 6V3265 | 48 CLIP | 1 | |
| 7F9090 | 49 SCREW-DRIVE (NO 8X3/8-IN) | 2 | |
| 5P2574 | 50 CONNECTOR | 1 | |
| 8M0547 | 51 ELBOW-FLARED (SWIVEL) | 1 | |
| 8S4951 | 52 CAP (FLARED) | 1 | |
| 9N0869 | 53 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 9S8752 | 54 NUT-FULL (3/8-16-THD) | 2 | |
| 1655970 | 55 SWITCH GP-TOGGLE (FUEL PRIMING) | 1 | |
| 9X6458 | 56 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 2147566 | 57 SEAL-O-RING | 1 |
