Assembly
100%

390-4768 SLOPER GP-POWERS/N P651-UP; LR61-UP; ML61-UP

Group No: 390-4768
Part NumberPart NameQty
9B01431 LOCKWASHER2
39452342 JACK GP-HEIGHT ADJUSTER2
39874333 SUPPORT AS (RH)1
39874344 SUPPORT AS (LH)1
3558941NUT-WELD (M16X2-THD)4
39951205 BOX (RH)1
39951216 BOX (LH)1
41679427 CLEVIS2
41679448 PIN AS-PIVOT2
41679479 PIVOT2
457895910 BUSHING4
457896011 BUSHING4
421318412 RING-RETAINING4
421400613 RING-RETAINING4
423090714 SPACER (21.5X38.1X29-MM THK)4
425351615 PIN2
425925216 COUPLING AS2
425925317 COUPLING AS2
5J3182SETSCREW-HEX SOCKET1
425925418 SPIDER2
444803719 STOP2
1D630620 NUT (1-8-THD)2
5P581321 LOCKNUT-BEARING (2.75X18-THD)4
5P883722 LOCK PIN2
7X051023 WASHER-HARD (15.5X29X3-MM THK)4
7X255524 BOLT (M16X2X80-MM)2
7X258125 BOLT (M30X3.5X100-MM)4
8C685426 BOLT (M14X2X50-MM)4
8C872227 NUT (M30X3.5-THD)4
8T038928 LOCKNUT (M10X1.5-THD)2
8T412129 WASHER-HARD (11X21X2.5-MM THK)4
8T413230 NUT (M16X2-THD)2
8T419331 BOLT (M16X2X50-MM)8
8T500532 BOLT (M10X1.5X70-MM)2
8T643033 BOLT (M20X2.5X50-MM)4
9X825734 WASHER (17.5X30X3.5-MM THK)8
9X825835 WASHER (33X56X6-MM THK)4
