433-4247 SLOPER GP-POWERS/N P651-UP; LR61-UP; ML61-UP

Group No: 433-4247

Part Number	Part Name	Qty
1D5120	1 NUT-JAM (3/4-16-THD)	2
2H3778	2 LOCKNUT	4
0657893	3 LOCKWASHER-BEARING	2
4932927	4 JACK GP-SLOPER	2
1022739	5 KEY-SQUARE	2
2225883	6 COUPLING GP	2
4B9806	SETSCREW-SOCKET (1/4-20X0.25-IN)	1
2772005	7 MOTOR GP-POWER ADJUSTER (ACTUATED)	2
2794231	8 FILM-IDENTIFICATION (SLOPE SCALE)	2
2796482	9 SPACER (38X21X20-MM THK)	4
2910068	10 SUPPORT AS	2
4213184	11 RING-RETAINING	8
4253516	12 PIN	2
4394348	13 BOX (LH)	1
4417518	14 PLATE	2
4417519	15 PIN AS-PIVOT	2
4420143	16 CLEVIS	2
4448037	17 STOP	2
4448502	18 INDICATOR	2
4578959	19 BUSHING	8
4626337	20 BOX (RH)	1
4L6454	21 BOLT (3/8-16X1-IN)	4
5P1076	22 WASHER-HARD (13.5X30X4-MM THK)	4
5P8837	23 LOCK PIN	2
7X2581	24 BOLT (M30X3.5X100-MM)	2
8C8722	25 NUT (M30X3.5-THD)	2
8T0389	26 LOCKNUT (M10X1.5-THD)	2
8T4121	27 WASHER-HARD (11X21X2.5-MM THK)	26
8T4132	28 NUT (M16X2-THD)	2
3445675	29 NUT (M10X1.5-THD)	8
8T4136	30 BOLT (M10X1.5X25-MM)	2
8T4175	31 BOLT (M16X2X90-MM)	2
8T4182	32 BOLT (M10X1.5X45-MM)	8
8T4956	33 BOLT (M12X1.75X35-MM)	4
8T5005	34 BOLT (M10X1.5X70-MM)	2
8T5460	35 BOLT (M20X2.5X40-MM)	4
9X8258	36 WASHER (33X56X6-MM THK)	2
