System And Components
8C-8160 DRIVE GP-CONVEYORS/N 1HD1-UP
Group No: 8C-8160
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C7765 | 1 SHAFT (OUTPUT) | 1 | |
| 8C7465 | 2 SEAL | 1 | |
| 9S7949 | 3 CUP-BEARING | 1 | |
| 9S7950 | 4 CONE-BEARING | 1 | |
| 8C7767 | 5 HUB | 1 | |
| 8C8138 | 6 WASHER | 1 | |
| 8C7470 | 7 LOCKWASHER | 1 | |
| 8C8139 | 8 LOCKNUT | 1 | |
| 8C7766 | 9 HUB | 1 | |
| 0300061 | 10 CONE-BEARING | 1 | |
| 8C8141 | 11 RING | 1 | |
| 0300060 | 12 CUP-BEARING | 1 | |
| 8C7471 | 13 GEAR (INTERNAL) | 1 | |
| 0871183 | 14 WASHER (THRUST) | 1 | |
| 9X0875 | 15 WASHER-THRUST | 2 | |
| 8C7472 | 16 CARRIER | 1 | |
| 8C7768 | 17 WASHER | 6 | |
| 8C7769 | 18 ROLLER | 96 | |
| 9X0887 | 19 SPACER | 3 | |
| 8C7770 | 20 SHAFT (PLANET) | 3 | |
| 0869743 | 21 GEAR-CLUSTER | 3 | |
| 2L5893 | 22 PIN-SPRING | 3 | |
| 9X0880 | 23 BOLT-SPECIAL | 4 | |
| 0869745 | 24 GEAR-RING | 1 | |
| 9X0876 | 25 SEAL-O-RING | 2 | |
| 8C8147 | 26 COVER | 1 | |
| 8T8912 | 27 BOLT (5/16-18X2.25-IN) | 8 | |
| 0869744 | 28 GEAR-INPUT | 1 |
